Plug and play heat recovery unit

Increasingly high demands are being placed on the air quality in buildings. Multiple ventilation is often needed in order to comply with these demands. A great deal of energy is lost when standard ventilation equipment is used. To counter the loss of energy, Mark has included a heat recovery unit, the AIRSTREAM, in its product range. The unit has an efficiency upto 90%. This means that 90% of the energy expelled is supplied to the fresh intake air. This high-efficiency means that in many cases no after-heating is required.

The AIRSTREAM heat recovery unit is available in two versions for both indoor and outdoor installation. The AIRSTREAM CFX is equipped with a certified high-efficiency counterflow heat exchanger with bypass. The AIRSTREAM HWX is equipped with a corrosion-resistant rotary heat exchanger.

Possible applications for the AIRSTREAM include offices, schools, workshops and changing areas.

Plug & Play

The Mark AIRSTREAM heat recovery units are supplied Plug & Play as standard. For efficient and proper operation, the units are equipped with a fully integrated control: the OJ-Air2 control. This control is programmed on a project basis. If you want to realize your own control, we can internally wire the air handling units up to a terminal box.

Features

• Efficiency > 90%
• Air amounts between 600-45000 m³/h
• 45 mm environmentally friendly foam sandwich panel
• The outer panelling consists of galvanized plate coated in RAL 9002 (white – grey) Other colors available on request at extra cost.
• The internal panelling is made of Magnelis ZM310 with a C4 corrosion resistance
• Thermal-bridge-free cabinet construction with aluminum profiles
• Seamless connection of the panels to the inside with rubber seal (hygienic)
• High external pressure possible
• Removable doors
• Indoor and outdoor installation
• Low noise level
• Plug & Play-version
• Supplied pre-assembled
• Various construction types possible as standard as well as specials on request
• Plug Fans equipped with energy-saving EC-motors
• Certification according to RLT Richtlinie-01

Optional

• Pre- and re-heating: electric, gas, water, change-over
• Cooling coil
• Heat pump (integrated or supplied seperately)
• Indirect adiabatic cooling

Cooling and heating with the TANNER MDA+

In addition to the standard TANNER MDA, Mark Climate Technology also has the MDA+ in its range. The TANNER MDA+ is suitable for both heating and cooling thanks to the integrated drip tray and optional condensate pump.

The TANNER MDA+ is a water-supplied hanging air heater/cooler suitable for horizontal air discharge. The unit has a powerful EC axial fan, which means that the MDA+ has many applications, such as in industrial halls, production areas and garages.

The air heater can also heat and cool with low water temperatures and small temperature differences. This means that the TANNER MDA+ can also be combined with a heat pump.

The TANNER MDA+ also features a completely new design.

Product features

• Integrated drip tray
• Optional: condensate pump
• Supplied as standard in a corrosion-resistant Aluzinc casing
• Copper/aluminium heat exchanger
• IP 54
• Units with AC motor on request
• Modern design

Air-to-air VRF heat pump system for heating and cooling large spaces

The Mark MISTRAL MDX is a VRF system, which is specially developed for energy-efficient heating and cooling of large spaces. The combination of an air-to-air heat pump (outdoor unit) with a compact air heater / cooler (indoor unit) ensures excellent performance. Thanks to the extensive setting options, the installation can be fully adapted to the use of the building and the wishes of the users.

Thanks to the long available pipe lengths (90m MDX 33/ 170m MDX 56) and the wide temperature range, the MISTRAL MDX has many application options. Suitable for heating and cooling garages, warehouses, workshops, distribution centers and showrooms.

Ambient temperature range (indoor unit)

• Cooling: +17°C – +43°C
• Heating: +7°C – +25°C

Product features

• Available with powers of 33 kW and 56 kW
• Air to air heat pump VRF-system
• Cooling and heating
• Large temperature range
• Indoor unit with EC fan
• Energy efficient
• Pipe length: 90m MDX 33 / 170m MDX 56
• Refrigerant: R410a
• Optional: integrated condensate pump

A radiant panel offers the option of heating without displacing air. In addition, heat reaches only the location where it is required. The short warming-up period and the lower room temperature can yield good energy savings. The panels are very suitable for heating with low water temperatures (40/30 ºC) using, for example, a heat pump.

Mark Climate Technology has two types of radiant panels in its range. The INFRA AQUA DESIGN is an aluminum radiant panel with an aesthetically pleasing appearance. The INFRA AQUA ECO is a lightweight panel for economical heating and cooling. The panels have a very wide area of application in both utility and industrial buildings. The panels may even be integrated into a system ceiling. We are happy to advise you on which product is the best application for your project.
