ARTICULATED VIDEOSCOPE 2 WAYS 3,9 mm (HU23157)

Works on electric vehicles (Tesla, Zoe, Leaf, Hyundai, Kia, etc.).
Ideal for modern vehicles with double triangulation.

• Supports the strut on the vehicle: 500 kg
• To be mounted on 30 mm hydraulic transmission
• POM (polyoxymethylene) clamping jaws to avoid damage to the strut. 3 sizes of jaws (light vehicle, light commercial vehicle, rear shock absorbers)
• Depth and tilt adjustment

Ideal for the following operations :

• Removal and installation of struts
• Removal and installation of drive shaft
• Removal and installation of arms and hub ball joint separation
• 100% safe work
• Operator has both hands free to work safely

No risk of damage to parts as :

• Sensors
• Wiring harness
• Plastic protection, body

Security :

• Once the tool is placed, the operator has both hands free to work safely.
• The tool supports up to 500 kg of pressure

Productivity :

• The tool is placed in less than a minute
• Dismantling of a strut in 7 to 8 minutes
• No risk of damage to mechanical parts or bodywork

Creativity :

• Patented tool
• Axial adjustment in 5 positions
• 120° articulation to respect the geometry of the suspension

The HU35060 digital pressure tester replaces dozens of analog testers with a single high-precision digital device. It ensures reliable and fast measurements - both pneumatic and hydraulic, allowing comparison between the physical values measured in the circuit and those read by diagnostic tools.

This kit can therefore measure Diesel and petrol compression, oil pressure, turbo pressure, cooling system pressure, AdBlue pressure, fuel low pressure, vacuum pressure and particle filter pressure and as an option, fuel high pressure.

The kit includes :

• Tester (Tablet)
  • WIFI connection for automatic test result uploads (traceability and warranty proof) and automatic software updates
  • wireless connection with the module
  • User-friendly touchscreen
  • USB-C port for fast charging
  • Dual reading : possibility to connect 2 sensors simultaneously
• Wireless Module
  • compact and perfect for road tests
  • communicates directly with the tablet in the vehicle via Bluetooth/Wifi
  • Built-in Lithium battery with real time charge status displayed on the tablet
• Sensor 0 to 300 bar
• Sensor 1 > 3 bar
• Universal Diesel compression adaptor
• Universel petrol compression adaptor
• 9 specific professional quick coupling adaptors ("T" adapters with SAE connectors)
• Vacuum adaptors

Also available : many accessories for specific applications, compatible with this kit. For example : Cylinder leakage tester, high pressure adapter set (both for Gasoline or Diesel) , Air conditioning adapter set, etc

Hubitools reinvents the brake bleeder !

Professional brake bleeder available in 2 configurations, 3 possible power supply modes, fully electronically managed and designed with one goal : reliability and robustness.

• LCD color screen and user-friendly 4 button touch panel
• Bleeding with adjustment from vacuum 0,5 bar to,pressure 4,5 bar
• Automatic leveling of the master cylinder’s reservoir
• 5 languages
• Psi and bar
• Automatic stop when the new DOT drum/can is empty
• Many safety functions such as automatic stop when the bleeder detects an abnormal pressure
• Works for brake and clutch bleeding
• Pulsating pressure
• Interchangeable drum/dan and flushing mode for different DOT use
• Flexible length : 5 m
• Includes EU standard master cylinder cap adaptor
• Includes old fluid retreiving bottle with nip adapter and chain

What makes it different ?

• Uses a EU made high quality gear pump
• Clever managment of the hydraulic system thanks to the specific software, making it highly reliable
• One-piece hydraulic system without return line
• Robust design with quality material to withstand tough garage environment
• Versatile (configuration – power supply – capacity...)

Configurations:

• HU11030: Portable version up to 20 L
• HU11035: On trolley version up to 60 L

Also available :

• HU11036: Trolley only (to upgrade the portable version to on trolley version)
• HU11038 : optional 230V to 12V DC Power Supply
• HU11030-9 : Battery Holder to fit a M12 battery as power supply

EV & Hybrid Vehicle Diagnostics Made Easier

As hybrid and electric vehicles become the new standard, technicians face growing challenges: strict safety procedures, insulating gloves, and increasingly complex connectors.

The new HU31045 EV & Hybrid Test Lead Kit has been specifically designed to simplify EV & Hybrid testing (VAT & Insulation) while maintaining the highest levels of safety and reliability.

Patented, universal, and compatible with most EV connectors (including Interlock connections), the HU31045 enables technicians to safely perform voltage absence, continuity, and insulation tests using their existing diagnostic equipment, even while wearing insulating gloves.

Its innovative design also allows these tests to be carried out by a single technician, improving workshop efficiency.

Designed with a 4mm banana plug connection on the tester side.

Compatible with:

• Voltage Absence Tester (VAT)
• Multimeter
• Megohmmeter (Insulation Tester)

Standards and safety:

• CAT III 1000V / CAT IV 600V
• IP2X retractable caps
• Load Limit: 12A
• NF EN IEC 62196-2
• CE & UKCA compliant

Works on electric vehicles (Tesla, Zoe, Leaf, Hyundai, Kia, etc.).
Ideal for modern vehicles with double triangulation.

• Supports the strut on the vehicle: 500 kg
• To be mounted on 30 mm hydraulic transmission
• POM (polyoxymethylene) clamping jaws to avoid damage to the strut. 3 sizes of jaws (light vehicle, light commercial vehicle, rear shock absorbers)
• Depth and tilt adjustment

Ideal for the following operations :

• Removal and installation of struts
• Removal and installation of drive shaft
• Removal and installation of arms and hub ball joint separation
• 100% safe work
• Operator has both hands free to work safely

No risk of damage to parts as :

• Sensors
• Wiring harness
• Plastic protection, body

Security :

• Once the tool is placed, the operator has both hands free to work safely.
• The tool supports up to 500 kg of pressure

Productivity :

• The tool is placed in less than a minute
• Dismantling of a strut in 7 to 8 minutes
• No risk of damage to mechanical parts or bodywork

Creativity :

• Patented tool
• Axial adjustment in 5 positions
• 120° articulation to respect the geometry of the suspension

The HU35060 digital pressure tester replaces dozens of analog testers with a single high-precision digital device. It ensures reliable and fast measurements - both pneumatic and hydraulic, allowing comparison between the physical values measured in the circuit and those read by diagnostic tools.

This kit can therefore measure Diesel and petrol compression, oil pressure, turbo pressure, cooling system pressure, AdBlue pressure, fuel low pressure, vacuum pressure and particle filter pressure and as an option, fuel high pressure.

The kit includes :

• Tester (Tablet)
  • WIFI connection for automatic test result uploads (traceability and warranty proof) and automatic software updates
  • wireless connection with the module
  • User-friendly touchscreen
  • USB-C port for fast charging
  • Dual reading : possibility to connect 2 sensors simultaneously
• Wireless Module
  • compact and perfect for road tests
  • communicates directly with the tablet in the vehicle via Bluetooth/Wifi
  • Built-in Lithium battery with real time charge status displayed on the tablet
• Sensor 0 to 300 bar
• Sensor 1 > 3 bar
• Universal Diesel compression adaptor
• Universel petrol compression adaptor
• 9 specific professional quick coupling adaptors ("T" adapters with SAE connectors)
• Vacuum adaptors

Also available : many accessories for specific applications, compatible with this kit. For example : Cylinder leakage tester, high pressure adapter set (both for Gasoline or Diesel) , Air conditioning adapter set, etc

Hubitools reinvents the brake bleeder !

Professional brake bleeder available in 2 configurations, 3 possible power supply modes, fully electronically managed and designed with one goal : reliability and robustness.

• LCD color screen and user-friendly 4 button touch panel
• Bleeding with adjustment from vacuum 0,5 bar to,pressure 4,5 bar
• Automatic leveling of the master cylinder’s reservoir
• 5 languages
• Psi and bar
• Automatic stop when the new DOT drum/can is empty
• Many safety functions such as automatic stop when the bleeder detects an abnormal pressure
• Works for brake and clutch bleeding
• Pulsating pressure
• Interchangeable drum/dan and flushing mode for different DOT use
• Flexible length : 5 m
• Includes EU standard master cylinder cap adaptor
• Includes old fluid retreiving bottle with nip adapter and chain

What makes it different ?

• Uses a EU made high quality gear pump
• Clever managment of the hydraulic system thanks to the specific software, making it highly reliable
• One-piece hydraulic system without return line
• Robust design with quality material to withstand tough garage environment
• Versatile (configuration – power supply – capacity...)

Configurations:

• HU11030: Portable version up to 20 L
• HU11035: On trolley version up to 60 L

Also available :

• HU11036: Trolley only (to upgrade the portable version to on trolley version)
• HU11038 : optional 230V to 12V DC Power Supply
• HU11030-9 : Battery Holder to fit a M12 battery as power supply
