QB.4 The new benchmark in brake testing

Realtime control via smartphone or tablet
• Optimized for mobile displays as default option
• No cabinets, no PCs, no license costs
• Optional display options: analogous, digital, or TV

Next level power box
• All electronic components safely stowed away
• Flexible display options, no need for a Windows PC
• RJ45 ethernet with ASA Livestream V1.2 interface as standard

No compromises on quality
• Motor brake as standard
• Hot galvanized frame and base unit
• Long-lasting granulate coated rollers for high grip and low tyre consumption
• Reinforced bearings and high quality motors

Brake testing made easy
• Automatic testing procedure
• No remote control
• Automatic all-wheel-drive detection
• Program for electronic parking brakes

Brake tester QB.4:
Easy testing without configuration hassle
• One configuration, fully equipped – as standard
• Smartphone/tablet app always included
• Additional display options: TV, analog, digital
• Robust and reliable
• Ideal for test centers, workshop and dealership
• Electronics safely stored inside power box instead between the rollers
• Automatic testing procedure

Q.DAS: Beissbarth's fastest solution for ADAS calibration so far!

All new vehicles sold since 2022 onwards will be equipped with safety-relevant advanced driver assistance systems (ADAS). Already today, these sensors need to be recalibrated even after minor repairs, but especially after a wheel alignment. This provides workshops with a new service
potential.
The new calibration solution Q.DAS allows workshops to perform the highly profitable service inhouse to safely return the vehicles to their customer.

Digital instead of analogue:
✔ Camera-based positioning and live guidance
✔ No plumb bobs or measuring tapes
✔ Full control over the positioning process
✔ Automatic specs* instead of manual inputs

Wheel alignment and ADAS calibration in one go:
✔ No repositioning of equipment
✔ No switching between equipment
✔ Always ready to go
✔ Guided procedure for setup and positioning
✔ Automatic compensation of different installation heights
✔ Complies with highest OEM accuracy demands

Calibration of safety-relevant ADAS:
✔ Forward facing cameras (e.g. Lane Keep Assist)
✔ Forward facing radar (e.g. ACC)
✔ For occasional as well as permanent use in front of alignment area

eTarget: digital display for calibration targets – with wide vehicle coverage
eTargets display the calibration targets on a glass free ePaper screen with reflective technology. This ensures high contrast even under extreme light conditions. The casing provides the eTargets protection during workshop use.

✔ Quick setups: 15 targets in one eTarget
✔ Automatic selection of the correct pattern
✔ High contrast even during extreme light conditions
✔ Less space requirements
✔ Documentation

Q.mApp: tablet software for camera and radar calibration
Q.mApp (Android) supports the user with simple step-by-step instructions to correctly setup, position, perform and document the calibration.

EasyTread - Tyre diagnosis at the vehicle reception with identification of the registration number

The tyres are the only contact points between a vehicle and the road. The quality of this bonds decides how safely the vehicle can be accelerated and braked. Especially aquaplaning can only be avoided by sufficient tread depth. This is why checking tread wear is a mandatory item of all statutory safety inspection. At the same time, uneven tread wear is a clear indication for a workshop that a wheel alignment should be considered - and that a wheel alignment check should be proposed to the customer.

• The Easy Tread needs only few seconds to calculate the tyre’s tread depths of a vehicle
• Clear display of tyre tread depth and wear information, within short time
• Recommended action are displayed (for the vehicle and/or the tyre)
• Crossing speed up to 8 km/h
• Can be integrated above ground in the workshop
• High precision thanks to the larger wheel contact area
• Browser-based measurement results on smart TV, PC or tablet computer
• No PC needed (can be however used to manage Customer-data, measuring data and statistics)
• Interface to connect the device in a customer owner system, where the data can be transferred for further processing (option)
• No moving parts (low maintenance)
• Measures in both directions of vehicle crossing over system
• Quality from Germany

An unbelievably bright idea: Our MLD 9000 headlight tester

Headlight testing procedure is a new challenge for workshops.

• continuous technological development
• new safety standards
• specific manufacturers calibration procedures
• expert know-how required for intelligent headlight tests

The solution is the digital headlight tester MLD 9000 by Beissbarth. It's suitable for all light sources and intelligent systems (matrix 1, matrix 2, DLA, ILS …). This product prepares the workshop to future challenges. The system can be kept up to date if new standard will be created from manufacturers.

The MLD 9000's measuring technology ensures the highest accuracy. Digital image processing using live images in real time allows for the precise testing and adjustment of various headlight types in an intuitive and speedy manner. Adjustment diagrams indicate actual and target values in a way that is both easy to access and understand. Additionally, acoustic signals will indicate that the headlights have been adjusted in accordance with the manufacturer's specifications and legal requirements. The user is guided through the evaluation and adjustment process, which makes the complexity of high-tech headlight designs manageable and offers the user complete control over the process.

An optional vertical laser kit supplements the MLD 9000. That way, the product can be aligned with the symmetrical axis of the vehicle and the headlight adjusted to meet the highest standards of manufactures. Owners of the ADAS calibration tool BBFAS 415/1415 by Beissbarth can use its laser for the MLD 9000 as well. Beissbarth also offers an inclination sensor for the product to deal with slightly uneven surfaces in the workshop.

In the future, measurement results can also be displayed directly on a computer by WLAN and linked to customer information.
