Features

*With one key leveling function, one key platform synchronization.

*The whole machine is designed by Italian team, using double oil circuit 8 oil cylinders design, equipped with double motor and double pump station, The scissor does not have any wires and electrical components connected to the control cabinet.

*The two-way side sliding plate has a one-button pneumatic unlocking function to facilitate rear wheel chassis adjustment.

*Control cabinet electrical parts modular, convenient later maintenance.

*The secondary platform has a lifting capacity of 4 tons and can be pulled and extended in two sections, suitable for vehicles with different wheelbases.

* Reinforced extended power-assisting arm for smooth and smooth lifting

Technical Parameters

Capacity of the main lifting 4000kg

Platform length of the main lift 4600mm

Platform Width of the main lift 663mm

Distance between platforms 800/900mm

Capacity of the lift table 4000kg

Platform length of the lift table(Two-way pull) 1499/1839/2309mm

Platform width of the lift table 663mm

Lifting time 45s

Lowering time 50s

Motor of the main lift 400/230V/3Kw /3ph /50Hz

Motor of the lift table 400/230V/ 1.5kw/2.2kw /3ph /50Hz

Lifting height main lift2060mm

Lifting height lift table 535mm

Minimum height main lift210mm
