FLEXBIMEC produces a wide range of pneumatic oil pumps that offers an appropriate solution for any kind of fl uid viscosity, required delivery, pumping distance, necessary outlet pressure, ambient temperature as well as for simultaneous fluid supplies and any type of storage container. The FLEXBIMECoil pump range is completed by the industrial pump series “Power Bull” with high delivery pumps for the supply of fluid lubricants in demanding conditions. These pumps are particularly recommended for the distribution of medium or high viscosity oils in applications or pipeworks where a simultaneous supply in different distribution points at high pressure and high delivery is required. The elevated quality of the used materials and the innovative constructional concept of the pneumatic motors of this line assure the following characteristics and advantages:

• Effi ciency of a constant flow,
• Low noise level,
• Limited number of piston strokes,
• Low vibrations,
• Easy maintenance and interchangeability of components,
• Included overpressure control valve,
• Included drain device for condensation water in order to avoid a spraying into the surrounding area.

Compression ratio 1:1 Compression ratio 3:1 Compression ratio 5:1

Art. no.2040

Art. no.2020

Art. no.2025

Art. no.2043/L - Art. no.2047/L

Art. no.2030

Art. no.2075/L

Art. no.2044 Art. no.2032 Art. no.2076

These pumps are recommended for the use

• at pumping distances up to 15 m,
• with low viscosity fluids.

These pumps are recommended for the use

• at pumping distances up to 100 m,
• with low and medium viscosity fluids.

These pumps are recommended for the use

• at pumping distances up to 200 m,
• with low and medium viscosity fluids,
• with high viscosity fluids at shorter pumping distances.

Oil SAE 0/40 Oil SAE 90 Oil SAE 240 Waste oil Antifreeze

Windshield

washer fluid

Art. no. Delivery

2040 48 l/min

2043 35 l/min

2043L 35 l/min

2044 35 l/min

2047 35 l/min

2047/L 35 l/min

2049 35 l/min

1045 35 l/min

2020 24 l/min

2030 24 l/min

2073 17 l/min

2074 17 l/min

2032 21 l/min

2033 21 l/min

2020TWDE 28 l/min

2030TWDE 28 l/min

2025 15 l/min

2035 15 l/min

2075 13 l/min

2075/L 13 l/min

2076 13 l/min

2061 18 l/min

2025TWDE 22 l/min

2035TWDE 22 l/min

2075/LTWDE 20 l/min

Industrial pump series “Power

Bull” Single acting models

Industrial pump series “Power

Bull” Double acting models

Oil

PNEUMATIC OIL PUMPS

Art. no.2012 Art. no.2013 Art. no.2016

Art. no.2092Art. no.2093 Art. no.2094

These pumps are recommended

• to achieve high deliveries in the use with low viscosity fluids (art. no. 2013),
• for the use with low and medium viscosity fluids at pumping distances of more than 300 m,
• for the use with high viscosity fluids at long pumping distances (art. nos. 2012 and 2016)
• for simultaneous fluid supplies.

See page 45!

These pumps are recommended

• to achieve very high deliveries in the use with low viscosity fl uids (art. no. 2098),
• for the use with low and medium viscosity fl uids at pumping distances of more than 300 m,
• for the use with high viscosity fl uids at long pumping distances (art. nos. 2055, 2056, 2096, 2097),
• for simultaneous fl uid supplies.

These pumps are recommended

• to achieve high deliveries in the use with low viscosity fluids,
• for the use with low and medium viscosity fluids at pumping distances of more than 300 m,
• for the use with high viscosity fluids at long pumping distances,
• for simultaneous fluid supplies.

See pages 46 and 48!

Art. no.2056Art. no.2055Art. no.2096 Art. no.2098

Art. no.2097

Oil SAE 0/40 Oil SAE 90 Oil SAE 240 Waste oil Antifreeze

Windshield

washer fluid

New modular system of hose-reels to enable the assembling in different size and hose rewinding capacity. .They can be equipped with hose driven device and brake to reduce rewinding speed. It is also possible to connect a solenoid valve to enable and manage , by suitable APP , the flow and the monitoring of the dispensing .

Electric pumps for the supply of grease and for high pressure lubrication in dispensing lines if only electrical power is available.
This series allows the combination of 3 different motors with different suction tubes and different planetary reduction gears, thus offering a total of 16 combinations which permit suitable solutions for various requirements

Automatic rewind, spring-driven hose reel, adjustable arms series EVO, in painted steel, suitable for hoses of max 25 m length and max diameter of 1/2”. The hose reel is supplied without hoses and can be used with hoses for the supply of oils, antifreeze, grease, compressed air and water. From the inlet swivel joint the fluid flows through an interchangeable hose connection adapter assembly on which the hose is mounted (standard version galvanized steel, available on demand also in stainless steel AISI 304 or AISI 316).Please see catalogue pages 228 and 229 for the selection of the required hoses. On demand the hose reels can also be supplied with a spring brake kit(see information at the end of this page!); please add suffi x “/HB” to the article number (f. ex. 9090/HB)!

Flexbimec manufactures a wide range of hose reels that guarantee a comfortable hose rewinding in all possible application fields and fluids such as:

• Lubricating oils and antifreeze
• Grease - Compressed air
• Water at low or high pressure
• Fuels
• AdBlue®/DEF/AUS32

The use of hose reels provides more security in the workshop and increases the life of hoses since those are no longer rest upon the floor after use where they could be damaged. In order to satisfy all application requirements the hose reels are available in two main materials:

• Epoxy powder-coat painted carbon steel
• Stainless steel AISI 304 (on demand also AISI 316)

The hose rewinding can be carried out:

• automatically by the use of a spring,
• manually by the use of a hand crank,
• by the use of a hydraulic motor,
• by the use of an electric motor.

The hose reel range can also be divided into 2 basic categories with regard on the hose diameter to be installed:

• Hose reels for hoses up to 1/2”
• Hose reels for hoses up to 1’ 1/2”

In order to be able to off er a suitable solution to any requirement existing in the market, various hose reel series have been developed.

The Flexbimec oil flow meter series MID MI-005 comply with metrological standards and requirements concerning accuracy as defined in the a.m. Directive and can be used therefore as approved meters also in legal transactions

MID-Oil Counter- Art. no. 2545

Electronic oval gears flow meter for oil, approved for legal transactions according to MID MI-005, Directive 2014/32/EU, with control gun, rubber protection guard, trigger guard, oil flow control pipe with sight glass, flexible rubber outlet, Ø 1/2”, with curved rigid 90° stem, automatic anti-drip nozzle and inlet swivel 1/2” BSP (M).

This flow meter fully comply the requirements of the OIML R117-1 (Dynamic measuring systems for liquids other than water – Part 1:

Metrological and technical requirements, edition 2007) and Welmec 7.2 software guide, May 2011.

Operating conditions for the use

Viscosity range of lubricants 94-185 mPa*s

Flow range 0.5 – 10 l/min

Min. measurable quantity 0.5 l

Accuracy class 0.5 (MID MI-005 – OIML R117-1)

Operating temperature range + 5°C / + 40°C

Working pressure range 1 – 20 bar

Display resolution degree 0.005 l

Mechanical environment category M1

Electromagnetic enviroment category E2

Checksum code cksum E57E

Protection class IP 64

Underlying CE directives

2004/108/CE

2006/95/CE

Underlying CE norms

CEI EN 61000-4-2

CEI EN 61000-4-2 A1

CEI EN 61000-4-2 A2

CEI EN 61000-4-3

Single operations data storing capacity 2000 record data

Composition of storable single operations data

Serial number of single delivery;

• Year of delivery;
• Month and day of delivery;
• Time of delivery;
• Dispensed quantity of single operation;
• Absolute total of dispensed quantities
