FLEXBIMEC produces a wide range of pneumatic oil pumps that offers an appropriate solution for any kind of fl uid viscosity, required  delivery, pumping distance, necessary outlet pressure, ambient temperature as well as for simultaneous fluid supplies and any type  of storage container. The FLEXBIMECoil pump range is completed by the industrial pump series “Power Bull” with high delivery pumps for the supply  of fluid lubricants in demanding conditions. These pumps are particularly recommended for the distribution of medium or high  viscosity oils in applications or pipeworks where a simultaneous supply in different distribution points at high pressure and high  delivery is required. The elevated quality of the used materials and the innovative constructional concept of the pneumatic motors of  this line assure the following characteristics and advantages:

• Effi ciency of a constant flow,
• Low noise level,
• Limited number of piston strokes,
• Low vibrations,
• Easy maintenance and interchangeability of components,
• Included overpressure control valve,
• Included drain device for condensation water in order to avoid a spraying into the surrounding area.

Compression ratio 1:1 Compression ratio 3:1 Compression ratio 5:1

Art. no.2040

Art. no.2020

Art. no.2025

Art. no.2043/L - Art. no.2047/L

Art. no.2030

Art. no.2075/L

Art. no.2044 Art. no.2032 Art. no.2076

These pumps are recommended for the use

• at pumping distances up to 15 m,
• with low viscosity fluids.

These pumps are recommended for the use

• at pumping distances up to 100 m,
• with low and medium viscosity fluids.

These pumps are recommended for the use

• at pumping distances up to 200 m,
• with low and medium viscosity fluids,
• with high viscosity fluids at shorter pumping distances.

Oil SAE 0/40 Oil SAE 90 Oil SAE 240 Waste oil Antifreeze

Windshield

washer fluid

Art. no. Delivery

2040 48 l/min

2043 35 l/min

2043L 35 l/min

2044 35 l/min

2047 35 l/min

2047/L 35 l/min

2049 35 l/min

1045 35 l/min

2020 24 l/min

2030 24 l/min

2073 17 l/min

2074 17 l/min

2032 21 l/min

2033 21 l/min

2020TWDE 28 l/min

2030TWDE 28 l/min

2025 15 l/min

2035 15 l/min

2075 13 l/min

2075/L 13 l/min

2076 13 l/min

2061 18 l/min

2025TWDE 22 l/min

2035TWDE 22 l/min

2075/LTWDE 20 l/min

Industrial pump series “Power

Bull” Single acting models

Industrial pump series “Power

Bull” Double acting models

Oil

PNEUMATIC OIL PUMPS

Art. no.2012 Art. no.2013 Art. no.2016

Art. no.2092Art. no.2093 Art. no.2094

These pumps are recommended

• to achieve high deliveries in the use with low viscosity fluids (art. no. 2013),
• for the use with low and medium viscosity fluids at pumping distances of more than 300 m,
• for the use with high viscosity fluids at long pumping distances (art. nos. 2012 and 2016)
• for simultaneous fluid supplies.

See page 45!

These pumps are recommended

• to achieve very high deliveries in the use with low viscosity fl uids (art. no. 2098),
• for the use with low and medium viscosity fl uids at pumping distances of  more than 300 m,
• for the use with high viscosity fl uids at long pumping distances (art. nos. 2055, 2056, 2096, 2097),
• for simultaneous fl uid supplies.

These pumps are recommended

• to achieve high deliveries in the use with low viscosity fluids,
• for the use with low and medium viscosity fluids at pumping distances of more than 300 m,
• for the use with high viscosity fluids at long pumping distances,
• for simultaneous fluid supplies.

See pages 46 and 48!

Art. no.2056Art. no.2055Art. no.2096 Art. no.2098

Art. no.2097

Oil SAE 0/40 Oil SAE 90 Oil SAE 240 Waste oil Antifreeze

Windshield

washer fluid
