Capacity: 600 litres
Internal dimensions: 1300 x 800 x 665 mm. (excluding auxiliary tank)
Useful measurements: 1240 x 636 x 415 mm.
Platform dimensions: 1245 x 636 mm.
External dimensions: 1740 x 1040 x 1070 mm. (including auxiliary tank)
Weight: 400 Kg.

ELECTRIC CHARACTERISTICS

• Power Supply: 400V.
• Heating element: 9000W.

ULTRASONIC CHARACTERISTICS

• Ultrasonic Power: 5100W. (10200W. p-p).
• 2 Ultrasound generators with a total output power of 5100 W (10200 W p-p).
• Working frequency: 40 KHz with a frequency sweep System (Sweep System ± 2%). 3 submersible emitters of 1700 W each.

CONTROL PANEL

• 4.3” TFT LCF touch screen. Functional and intuitive; with access to select the time of the ultrasounds, temperature and peripherals or optional systems; and it is programmable on a weekly calendar.
• PLC with a temperature model fitted with 7 outputs and 7 inputs.

FINISHING AND ACCESSORIES

• AISI 304 stainless steel tank, 2.5 mm thick.
• K-Flex Duct Net thermal and acoustic insulation, 20 mm.
• Exterior steel panelling with a special anti-fingerprint finish. Easy to clean.
• Reinforced pneumatic platform for loading, packing and unloading with capacity for 350 Kg.
• ½” water inlet ball valve and a 1½” one for drainage.
• Silentblock legs, adjustable in height
• Heat-insulated stainless steel end-of-day lid.
• Compressed air gun to dry parts. Ancillary external tank to separate lubricants and oils. Removes residue from the surface of the ultrasound tank, keeping the cleaning equipment in perfect condition.
• Sloping bottom to facilitate cleaning.

AUTOMOTIVE

• Grinding workshops
• Turbocharger workshops
• Engine rebuilding work
• Gearbox repair shops
• Marine
• Heavy machinery

INDUSTRIAL EQUIPMENTS

• Aeronautic industry
