MOT-185 Advanced - Ultrasonic cleaner - 185 litres
ELECTRICAL CHARACTERISTICS
- Power: 220V / 18A - 400V / 12A
MEASUREMENTS
- Internal Measures: 760x520x600 mm.
- Platform measures: 730x455 mm.
- External Measures: 1140x930x1060 mm.
- Capacity: 185 liters
TECHNICAL DATA
Ultrasonic cleaning chamber built in AISI 304 stainless steel of 2 mm thickness and internal chamber of thermal-acoustic insulation of 20 mm thickness.
Opening lid - closure in polypropylene with double wall of 4 mm thickness and thermal-acoustic insulation of 20 mm thickness
Pneumatic platform built in stainless steel AISI 304, with a load capacity of 60 kg, regulator of rise and fall flow and condensation filter.
WFS (Separation of oils), independent tank of the cleaning tank for the capture of oils and particles on the surface of the main cleaning tank, minimum water level detector, drainage for the oil output and maintenance. Capacity 30 L.
Electrical resistance built in stainless steel AISI 316 L and a power of 3500 W.
Bag filter TTF1 (optional) for the removal of sludge from the bottom of the tank made of stainless steel AISI 304, manometer and the possibility of integrating bags of 5 to 200 microns.
GENERATOR AND EMITTERS
Ultrasonic generator, output power of 1700W (3400W p-p) with automatic power monitoring and frequency wave. Frequency of work 40 KHZ, Sweep System 2%.
Ultrasonic emitter, power of 1700W (3400Wp-p) built in stainless steel AISI 316L of 2.5 mm thickness, with piezoelectric transducers IBL steel-titanium high performance.
CONTROL PANEL
7 "screen and TFT display Intuitive screen with direct access to all functions and the possibility of creating different work programs.
Programming in all languages, weekly calendar, time control for preheating the equipment and alarms.
ADVANTAGE
- RAPIDITY OF CLEANING, our high technology of generator-emitter of ultrasounds achieves that 100% of the power emitted concentrates in the area of washing achieving a performance of 20-30% superior to any other equipment of the market.
- COMPLETELY SILENT, between 50-60 dB depending on the type of detergent we use.
- ENERGY SAVING, above 50% due to the perfect insulation and sealing of the equipment.
- ATER SAVING, we minimize the consumption of water and detergent, since we do not have losses by evaporation.
- ROBUST AND MAINTENANCE, due to its design and materials used, we obtain a robust and easy maintenance equipment.
