General measurements mobile workbench:
Height: 725mm
Height (with wheels): 888mm
Width: 730mm
Length: 1140mm

Drawers dimensions:
(6x) 570x410x83mm
(2x) 570x410x112mm
(2x) 570x410x228mm

Cabinet measurements:
600x190x600mm

Characteristics:
Wooden board
Drawers structure thickness: 0,8-1,2mm
Drawers thickness: 0,8mm
Packing dimensions: 1190x770x1036mm

Characteristics:
Capacity: 500kg
Minimum height: 1189mm
Maximum height: 2000mm
Product weight: 28,5kg
Double pump (Quick lift)
With safety valve

Description:
•The maximum load capacity is 0.5 ton
•DO NOT exceed this rated capacity
•This jack is used as an aid in the removal and installation of a transmission or a differential as individual components
•DO NOT use it for any other purpose it is not designed to perform
•DO NOT use this transmission jack as a vehicle lifting device or as a vehicle support
•Only use this equipment on a surface that is stable, level, smooth and capable of sustaining the load
•Keep the surface clean, tidy and free from unrelated materials and ensure that there is adequate lighting

Characteristics:
Capacity: 10T
Minimum height: 160mm
Maximum height: 685mm

Characteristics:
Drive: Electrical hydraulic
Max lifting weight: 4T
Lifting height: 1760/1790mm
Initial height: 100/130mm
Lifting time: ≤50S
Lowering time: ≤60S
Pass width: 2436mm
Overall width: 3440mm
Overall weight: 671 kg
Machine power: 2.2 KW
Hydraulic oil: 7L 20＃
Working temperature: 5-40℃
Working humidity: 30-95%
Noisy level: < 76db
Storage temperature: -25℃~55℃
Installation place: Indoor

Usage:
•This two post lift can lift various vehicles which weight is less than 4000Kg
•And it is suitable for vehicle test, repair, maintenance and care
•This lift is designed to lift vehicles, not for other usage
•Forbid to use for washing and spraying vehicles
Features:
•Design and manufacture according to relevant standard, and machine performs stable and reliable
•With hydraulic locking and mechanical locking system, safety and reliable
•With safety valve and antiknock valve in case of hydraulic failure or over loading, to prevent the lift from lowering quickly when oil pipe bursts
•Double cylinder drive, to lift and lower stably
•Adopt imported hydraulic and electrical components from Italy, Germany and Japan
