OPA 105.PCB Battery-operated partial-flow Smoke Meter Module

The OPA 105.PCB is suitable for testing smoke and opacity emission of Diesel engine-equipped vehicles of any kind.
Available as full version for heavy-duty emission tests or as light version for pre-check, diagnostic and repair.

Powered by ASSEMBLAD OPA-KING, our own technology for ready-for-working temperature-controlled smoke bench.

To be used in conjunction with external pc running ASSEMBLAD software or connected to ASSEMBLAD Gas Analyzer for stand-alone combi emission test station.

Approved for statutory tests. Recommended for intensive use.

MAIN FEATURES:

• Available as light version or full version including smoke shut-off valve.
• Capable to run any emission test procedure on Diesel engine-equipped vehicles of any kind.
• User-selectable operating modes: free acceleration, continuous, loaded, etc.
• ASSEMBLAD Service software available for remote monitoring.
• Battery-operated, handy and portable.
• Automatic zeroing function (typical 15 sec.).
• Fast warm-up time (typical 5 minutes) at power-on only.
• Easy and quick maintenance, cleaning and calibration.

Fine Particle Counter to be used as Stand-alone equipment, or connected to a PC for integrated
use.
Can be a part of Assemblad integrated test line for motor vehicles.
With built-in backlit graphic display and keypad, it measures concentration of fine particles in ＃/cm³.

Available both as light and full version, which includes the heated probe for legislation compliant
measures, if required.

- Suitable for all Diesel vehicles, with the cold probe (optional) recommended for pre-check,
dignostics and repair, while the heated probe (include in full version) is for use as in statutory
inspections.
- Powered by Diffusion Charge technology, clean and long-lasting without need of any flammable
liquid to be operated.
- Long-lasting operativity, requiring a simple annual maintenance check / calibration to maintain
operativity.
- Optional accessories: bluetooth printer, heated / cold probe, bluetooth interface.

Roller brake tester for light and heavy-duty commercial vehicles

Complying with international testing specifications for statutory technical inspections, the F3318-1 roller brake tester can test heavy duty vehicles up to 18 tons, and in the optional combi version can test also vehicles below 3.5 tonnes.

Other options such as 4 wheel-drive, integrated lifting for load simulation, and compressed air measurement are also available.

Manufactured as split bench for flexible installation, inexpensive transportation and easy handling, the F3318-1 is fit to be assembled either as joint bench for in-floor recessed installation or as split bench for pit installation.

Epoxy corundum-coated rollers to meet or exceed international standard for statutory inspections.

MAIN FEATURES:

• Optional combi version to include vehicles below 3.5 tonnes.
• Manufactured and delivered as split bench suitable to be installed either as joint bench for in-floor recessed installation or as split bench for pit installation.
• Compliant with ISO 21069-1, EU 2014/45 Directive and relevant international standards.
• Long-lasting epoxy corundum-coated rollers, suitable for remanufactoring.
• Available as dedicated brake tester as well as module for complete inspection line under the management of Windows-compatible ASSEMBLAD test line software.

High performance, battery operated exhaust gas analyser module with infrared technology and connection to a PC serial port.

Available as 4-gas (CO, CO2, HC and O2) and 5-gas (CO, CO2, HC, O2 and NOx) version.

Suitable for testing emissions of Otto-cycle engine-equipped vehicles of any kind, recommended for intense use as in statutory tests.

Powered by ASSEMBLAD INFRA-QUEEN infrared gas bench.

To be used in conjunction with external pc running ASSEMBLAD software or connected to ASSEMBLAD Smoke Meter for stand-alone combi gas/smoke emission test station.

Approved for statutory tests. Recommended for intensive use.

The F3218 is the longest plate brake tester for light and heavy-duty commercial vehicles, with extended range to test more axles at the same time.

It is the most efficient and cost-saving method to test the braking efficiency of motor vehicles, allowing to test multi-axle trucks in a few minutes, with impressive savings on the energy bill compared to the traditional roller brake tester, as it has no engines to be activated.

It is equipped with epoxy corundum-coated plates and double weight + brake gauges to meet or exceed international standard for statutory inspections.
It is avaiable in various lengths, from 2 to 16 plates and more, to test any heavy duty vehicle on the market quickly.

Other characteristics:
- Suitable for recessed and surface installation with ramps.
- Electronic box and interface and Windows-compatible software included
- Test speed: 6 km/h
- Wheel track: 800-2800 mm.
- Max axle load: 18 tonnes.
