Magnetite separators especially for heat pumps

Low pressure loss, high performance with a large flow range, a large collecting vessel, an extremely strong magnet as well as a fine-meshed filter network, ideally matched for hydraulic system conditions of heat pumps, but also wood heating systems: the new magnetite and sludge separators.

How it works

The MP1 and MP2 magnetite and sludge separators are equipped with a powerful neodymium magnet with 11,000 gauss as well as a fine-mesh filter insert. Due to this dual action, they reliably filter all magnetic and non-magnetic impurities from the heating system. The particularly large collection container makes both ideal for systems with heat pumps or wood heating systems.

How dual filtration works

Due to the change in cross-section of the filter chamber compared to the pipe, the heating water slows down there, the close-meshed filter insert catches all non-magnetic impurities exactly there. The magnetic impurities, such as magnetite, are then attracted and intercepted by the magnet mounted in the centre of the filter chamber. In this way, magnetic or ferrous and non-magnetic impurities are removed from the system and collected at the bottom of the large collection tank.

Maintenance

All necessary shut-off, draining and venting devices for maintenance are already integrated on both separators ex works. The drain ball valve is located at the bottom of the collection tank, the shut-off device and venting at the top of the filter housing. Without having to open the filter, the strong neodymium magnet can be pulled out downwards. Depending on how dirty the system is, this maintenance can also be carried out with cleaning of the filter screen. The unrivalled capacity of the collection tank accommodates longer maintenance intervals.

MP1 or MP2 - The difference is the installation situation

Magnetite and sludge separators should always be installed in the return before the heat generator to protect it from contamination, which usually comes from the system. However, not every system always offers enough space. The 28.5 cm high and 10 cm wide MP1 model stands out because of its large collection container. It should only be installed in horizontal pipelines. The more compact MP2 model is recommended for installation situations where there is not enough space. It can also be rotated 360° via the union nut of the diverter valve housing and installed horizontally, vertically or diagonally in almost all installation positions. Both models have a 1" connection and optional thermal insulation is available to maintain the heat level for reduced energy consumption, energy costs and CO2 emissions.

RBM and Orben

Since 2022, RBM and Orben Water Treatment have been going their separate ways in the D-A-CH region. Orben exclusively represents the range of magnetite, sludge and air separators in the three-stage distribution channel. The contact persons for the trade and wholesalers are Orben's experienced industrial and commercial representatives.

The family-owned company RBM from northern Italy with a turnover in the three-digit million range was founded in 1953 by the Bossini family near Brescia in northern Italy. The specialist has four of its own production facilities in the Brescia area near Lake Garda and six branches worldwide with more than 250 employees. RBM stands for an extremely high and automated vertical range of manufacture. The ultra-modern production facilities in nearby Italy guarantee a high level of delivery readiness, especially in times of strained global supply chains, and the ability to respond quickly and flexibly to new requirements and customer wishes thanks to in-house development and production. Especially in the field of magnetite and sludge separators, a large number of innovations have been successfully placed in other European countries in recent years.

Orben repleneshing systems for heating water.

Fully demineralised heating water protects the service life and efficiency of heating systems. The water treatment specialist ORBEN now offers a new complete range of stationary refill stations for the standard-compliant replenishment of heating water.

The ready-to-connect refill cartridge systems, available in various sizes with or without system separator, ensure optimum and standard-compliant treatment of the make-up water according to VDI 2035 (as well as ÖNORM H 5195-1 and SWKI BT 102-1) for small and medium-sized systems.

Two series in different sizes

The "Serastil NKS ready" series combines an automatic filling valve with system separator type BA and a desalination cartridge as a complete treatment concept. The system separator, which is equipped with a thermal insulation shell, includes a wastewater connection in accordance with DIN EN 1717 and thus fulfils the separation of the two systems required in the case of short-term and permanent contact between the freshwater pipe and the service water installation (i.e. the drinking water network and the heating system). The refilling station is further completed by pressure reducers to prevent pressure surges in the heating system, a double manometer to display the inlet and outlet pressure as well as shut-off valves at the inlet and outlet of the filling combi (½"). The double manometer helps with troubleshooting if the heating system has not been filled properly - it can be particularly helpful with fluctuating inlet pressures.

With the second series "Serastil NKS", the system separator must be available on site. With both series, a water meter for recording the replenishment water quantity, a ½" shut-off ball valve for regulating the replenishment quantity and safe shut-off complete the filling system. The automatic refill and treatment fitting complies with all normative requirements for heating water. The complete refilling and treatment system is designed for a maximum operating pressure of 8 bar, at a maximum temperature of 45° C.

Colour change and germ barrier

Both series are available with one, two or four cartridges. The maximum filling capacity is 60, 120 and 240 l/h respectively, with a capacity at 420 μs /cm to < 100 μS/cm of 115, 230 and 460 l. They are thus ideally suited for detached houses and apartment buildings. The high-performance cartridges for supplementary water are filled with Orben high-performance mixed bed resin as a variant with colour change. The more the resin is exhausted, the more the colour changes from blue to brown. The resin in the transparent cartridge thus reliably gives a change indication.

A germ barrier protects the make-up water from possibly contaminated supply water and prevents recontamination into the drinking water network. An integrated protective strainer additionally protects the heating system against possible resin leakage.

Heating and circuit water for jumbo-sized systems

The water specialist Orben is now able to quickly provide even extremely large quantities of treated heating or circulation water. The Jumbostil demineralisation systems supply 12,000 to 22,000 l/h of ultra-pure water, depending on demand. The rental offer is suitable for large residential and commercial buildings as well as for local and district heating systems.

Standard-compliant treated heating or circulation water ensures the long-term efficiency and trouble-free heat transfer of a heating system. For an immediate supply of ultrapure water, the Jumbostil rental cartridges from Orben are ready for connection and sturdily fixed to a steel transport frame. For the cartridges weigh between 340 kg and 1200 kg and are more than 2 m high.

Standard-compliant ultrapure water in large quantities

They are filled with the manufacturer's own ion exchange resin "Thermion 2035 pH conform". The mixed-bed resin automatically regulates the pH value and produces heating water according to VDI 2035 / EN 1686 for domestic and building services as well as for district and local heating networks according to AGF 510. Depending on the application and the size of the system, the ultrapure water output is between 12,000 l/h and 22,000 l/h. The resin has been proved to contain a high percentage of pure water. According to the manufacturer, it demonstrably contains fewer ionogenic impurities than a distillate and is therefore of extremely high quality. For even larger quantities of ultrapure water, Orben also rents out trailer systems with an ultrapure water capacity of 60,000 l/h per trailer on request.

Treatment service on behalf of the trade

The standard rental period for the demineralisation systems via the three-stage distribution channel is four weeks, or for longer periods on request. On behalf of the trade, the nationwide Orben Service offers heating water treatment in accordance with standards as a service to relieve the trade. The service includes a detailed construction discussion and coordination with the client, the assumption of travel costs and labour costs, the provision and commissioning of the Jumbostil including consumables costs (ORBEN high-performance resin "THERMION 2035 pH conform" and 1 µm filter insert), the measurement and evaluation of the required analysis values according to DIN EN 14336 and VDI 2035 and the documentation of the analysis values, including a photo series in a system book.

Further information at: www.orben.de

Mobile filling system for heating water treatment from ORBEN

The water treatment specialist ORBEN offers a new, ready-to-connect mobile complete system for heating water filling in the bypass process in accordance with VDI 2035 and DIN EN 14336. Treatment takes place in just one step, all system components are assembled ready for operation.

The mobile heating water filling unit Thermostil mobil 4000 is ideal for small and medium-sized systems including buffer tanks of up to 2,000 l or for

up to 3,000 l with pure system water content. The circulation capacity in bypass mode is approx. 600 l/h. All necessary components are installed ready for connection: a fine filter for fine filtration up to 1 μm, a magnetic flow filter for magnetite and sludge removal, and a highly efficient heating circulation pump (12 mWS). The filling mobile for heating water treatment is quickly and safely connected to the heating circuit via thermo connection hoses including quick connectors (maximum flow pressure 1.5 bar, maximum operating pressure 6 bar). The quick connectors are safely stored on the unit thanks to clip holders.

The robust stainless steel cartridge (23 l) including LED conductivity indicator for checking an imminent change contains the high-performance resin Thermion2035 ph-conform. It is specially optimised for heating filling and heating water treatment in the bypass process and ensures full desalination of the heating water in accordance with VDI 2035. The capacity of one filling at 420 μS / cm to < 100 μS is 3590 litres. The pH value is thereby reliably and automatically regulated and can be operated at a maximum temperature of 80° C for the filling of heating circuits. A water meter installed on the unit as well as a test tap support the necessary measurement and documentation before and after treatment. All necessary measuring and testing equipment as well as a system logbook are also available. Delivery and on-site instruction are carried out via the three-stage distribution channel by a qualified ORBEN service technician.

ORBEN is the water specialist in the three-stage distribution channel. The water, heating water and circuit water experts offer a complete range of products, services and services for the initial filling or replenishment of heating systems in accordance with VDI 2035 / EN 1686 in domestic and building technology as well as district and local heating networks in accordance with AGFW 510. From mobile and permanently installed products for heating water treatment including inon-exchange resins to solutions for replenishment and services for small and large systems including accessories, ORBEN offers solutions for heating and circuit water.

Heating water filter mobile from ORBEN

Clean heating water protects and ensures the trouble-free performance of a system. For mobile cleaning of heating circuits, the water specialist ORBEN now offers the Thermostil Ultraflex system. The ready-to-connect mobile heating water filter removes magnetite, solid and suspended matter as well as dirt and foreign substances from the system water. Thermostil Ultraflex can also be rented to get to know the new system or for infrequent use.

With a heating water range of up to 90°C, the complete system filters all magnetic and non-magnetic deposits from the heating water of small and large systems. All components are mounted on a hand truck ready for operation: a combined fine and magnetite filter including filter bag for fine filtration down to 1µm, a tacosetter for adjusting the circulation rate, a water meter for recording the filtration rate, a connection for the optional connection of an ion exchanger cartridge and a highly efficient heating circulation pump. For an elevated position, the pump is fixed on a standing platform. The filtration mobile is connected to the heating circuit via thermo connection hoses including quick connectors (maximum operating pressure 6 bar).

Clean system water

Magnetite and rust sludge can cause malfunctions and damage in heating systems, for example to permanent-magnet high-efficiency pumps, the condensing boiler, heat exchangers or valves. This is because deposits that worsen heat transfer or impair control accuracy increase the effort and thus the costs involved in heat generation and transfer. Clean system water thus increases the service life of the heating system, protects its components and reduces running costs.

Also for rent and as a service

In addition to sales, Orben also offers the system to the trade for rent for a period of 4 weeks or more via the three-stage sales channel, as well as an extension option if required. The standard-compliant filtering of heating water is also part of Orben's extensive service programme, which the family-owned company can take over completely on behalf of the specialist tradesman, for example, in the event of high staff utilisation. For this purpose, Orben maintains a trained team of service technicians in its ten branches throughout Germany.

About Orben

ORBEN is the water specialist in the three-stage distribution channel. The water, heating water and circuit water experts offer a complete range of products, services and services for the initial filling or replenishment of heating systems in accordance with VDI 2035 / EN 1686 in domestic and building technology as well as district and local heating networks in accordance with AGFW 510. From mobile and permanently installed products for heating water treatment including inon exchange resins to solutions for replenishment and services for small and large systems including accessories, ORBEN offers solutions for heating and circuit water.
