Common Rail Test - TM 514

The test speed and the coding potential turn the TM514 into an incredible equipment for repair and test of INJECTORS, SENSORS and VALVES of vehicles with Diesel COMMON RAIL system.

With electronic pressure control and injectors activation through electric signals, the TM514II Test Bench simulates the working conditions found inside the vehicle´s engine, and executes tests in the main components of the market: Bosch, Denso, Delphi, Siemens, Cummins among others. Due to the efficiency of this machine the day will seem as if it has more than 24 hours.

Performs tests up to 2400 Bar

HIGHLIGHTS

Undisputable superiority

The TM 514 puts together some exclusive features:
• The fastest in the market with test times from 5 to 12 minutes
• Economy! More tests with less fluid (5,5 liters)
• Versatile! Generates codes for Bosch, Denso, Delphi and Siemens
• Brazilian equipment 100%

FEATURES

• Tests up to 2400 Bar
• Test of solenoid and piezo injectors
• Electric and leak test for each injector, in order to detect short circuits, interruptions and leaks. Get the results of the injector test in 5 to 12 minutes.*
• Get the results of the injector test in 5 to 12 minutes.*
• Solenoid Bosch, Denso and Delphi injectors as even as Piezo Bosch and Siemens injectors can be coded**
• Test the main components from the market using just one machine (Bosch, Denso, Delphi, Siemens, Cummins among others)
• It has an exclusive magnetic tools holder, that helps to organize better your workplace
• The TM514II executes several tests using just 5,5 liters of test fluid. This is ECONOMY!
• The software COMMON RAIL PC FAST has the biggest Database of Brazil and is being updated constantly.
• interface with friendly operation, easy interpretation and use.
• Online update
• Direct access to TECNOMOTOR! The user can get in touch with Technical Support by means of a CHAT embedded into the software, which makes the customer service much faster, safer and personalized.

TECHNICAL SPECS

• Input: 220V / 380V - 60Hz Three Phase
• Consumption: 5000VA
• Tank capacity: 5,5 liters
• Test fluid: ISO 4113 (Check the list of homologated fluids)
• Maximum work pressure: 2400bar
• Dimensions: 791 x 722 x 726 mm (L x W x H)
• Weight: 115Kg

Disther - TM 581

Disther is a compact, high tech module for valves actuation, pressure and flow measuring. It was developed for testing high pressure Diesel Common Rail pumps, supplying more reliability and precision with results never seen before in the American market.

By adding hydraulic connections, some sensors (pressure and rotation) and valves (rail and DRV) Disther turns your pump test bench into a modern and sophisticated equipment for pump valves actuation, pressure and flow measuring.

HIGHLIGHTS

EXCLUSIVE TECHNOLOGY

With Disther your test bench receives technological resources, with official manufacturer´s reference parameters, pressure control and digital flow measuring.

It has an exclusive diagnosis test plan that consists of a guided test enabling the performance analysis of the internal elements of the pump, which facilitates the repair work.

It tests pumps with synchronized actuation of the pressure valves, such as Denso HP5 (Toyota Hilux), Caterpillar (326-4634) among others.

MAIN FEATURES

• It includes pressure rail, inlet vacuum meter, pressure rail holder, harnesses and hoses.
• It tests high pressure pumps by following the parameters from the manufacturers (Bosch, Delphi, Denso, Caterpillar, among others).
• Its diagnose test plan aims to be a guided test that enables the performance analysis of the internal elements of the pump facilitating the repair work.
• Test of CR regular pumps.
• Test of CR synchronized pumps (Hilux | Caterpillar).
• Application table with reference parameters from manufacturers.
• Official and Diagnose test mode.
• 10.1” Touch Screen Display.
• Issuing of test reports with online sharing.
• Wi-Fi connection for updating and sending information.
• Pressure and flow electronic control with high precision digital measuring.
• Online updating.

TECHNICAL SPECS

• Power Input: 220V, 60Hz
• Consumption: 350W
• Display: 10.1’ (1280x800)
• Android: 8.1
• Wi-FI connection
• USB connection
• HDMI connection for screen mirroring
• Inlet test fluid filters 40u
• Equipment weight: 21 Kg
• Equipment weight + hoses + cables: 24,8 Kg

We are delighted to introduce the latest addition to our lineup: BOSCH CP4 / DELPHI DFP6 SHAFTS

Our manufacturing process ensures unparalleled quality assurance, delivering premium-grade products.

At ELKOSO we take pride in our unwavering commitment to manufacturing pump shafts of the highest quality. Our pump shafts are crafted from carefully selected, top-grade materials, ensuring superior strength, durability, and resistance to corrosion. Our team of skilled engineers employs cutting-edge design principles to create pump shafts that optimize performance, taking into account precise specifications and operating conditions. Our commitment to quality is unwavering, with comprehensive quality control measures at every stage of production. Non-destructive testing methods are employed to identify and eliminate any potential defects.

TEST EQUIPMENT FOR HPI INJECTORS AND TP ACTUATORS.CUMMINS/SCANIA

EQUIPMENT FOR HPI INJECTORS

With our team together with the cam-box you can perform the following tests

• Nozzle leak test
• Element pressure test.
• Return valve test.
• Injection advance and delay test.
• Delivery Flow.

Principal functions:

• Internal set of flow and advance control valves.
• Easy-to-use software, with semi-automatic tests.
• Test report.

EQUIPMENT FOR TP ACTUATORS

Equipment designed to perform tests and calibration of injection flow and time actuators.

• Static leak test.
• Dynamic Leak Test
• Flow test in 3 different conditions.
• Electrical race test.
• Isolation Test.

Principal functions:

• Dynamic flow measurement with high precision probes.
• Automatic feed pressure adjustment
• Easy-to-use software, with automatic tests.
• Database.
• Test Reports.
