Disther - TM 581

Disther is a compact, high tech module for valves actuation, pressure and flow measuring. It was developed for testing high pressure Diesel Common Rail pumps, supplying more reliability and precision with results never seen before in the American market.

By adding hydraulic connections, some sensors (pressure and rotation) and valves (rail and DRV) Disther turns your pump test bench into a modern and sophisticated equipment for pump valves actuation, pressure and flow measuring.

HIGHLIGHTS

EXCLUSIVE TECHNOLOGY

With Disther your test bench receives technological resources, with official manufacturer´s reference parameters, pressure control and digital flow measuring.

It has an exclusive diagnosis test plan that consists of a guided test enabling the performance analysis of the internal elements of the pump, which facilitates the repair work.

It tests pumps with synchronized actuation of the pressure valves, such as Denso HP5 (Toyota Hilux), Caterpillar (326-4634) among others.

MAIN FEATURES

• It includes pressure rail, inlet vacuum meter, pressure rail holder, harnesses and hoses.
• It tests high pressure pumps by following the parameters from the manufacturers (Bosch, Delphi, Denso, Caterpillar, among others).
• Its diagnose test plan aims to be a guided test that enables the performance analysis of the internal elements of the pump facilitating the repair work.
• Test of CR regular pumps.
• Test of CR synchronized pumps (Hilux | Caterpillar).
• Application table with reference parameters from manufacturers.
• Official and Diagnose test mode.
• 10.1” Touch Screen Display.
• Issuing of test reports with online sharing.
• Wi-Fi connection for updating and sending information.
• Pressure and flow electronic control with high precision digital measuring.
• Online updating.

TECHNICAL SPECS

• Power Input: 220V, 60Hz
• Consumption: 350W
• Display: 10.1’ (1280x800)
• Android: 8.1
• Wi-FI connection
• USB connection
• HDMI connection for screen mirroring
• Inlet test fluid filters 40u
• Equipment weight: 21 Kg
• Equipment weight + hoses + cables: 24,8 Kg

We are delighted to introduce the latest addition to our lineup: BOSCH CP4 / DELPHI DFP6 SHAFTS

Our manufacturing process ensures unparalleled quality assurance, delivering premium-grade products.

At ELKOSO we take pride in our unwavering commitment to manufacturing pump shafts of the highest quality. Our pump shafts are crafted from carefully selected, top-grade materials, ensuring superior strength, durability, and resistance to corrosion. Our team of skilled engineers employs cutting-edge design principles to create pump shafts that optimize performance, taking into account precise specifications and operating conditions. Our commitment to quality is unwavering, with comprehensive quality control measures at every stage of production. Non-destructive testing methods are employed to identify and eliminate any potential defects.

Elkoso, with years of unwavering commitment to precision engineering and innovation, stands as a prominent industry leader in the production of high-quality valves for common rail injectors.

Our seasoned expertise in this field has allowed us to develop cutting-edge solutions that set new standards for efficiency and reliability. With a keen focus on the intricate requirements of common rail systems, Elkoso’s valves are meticulously crafted using state-of-the-art manufacturing processes. Our skilled team, backed by years of experience, ensures that each valve meets stringent quality standards, providing optimal performance and durability.

As a trusted name in the industry, Elkoso continues to play a pivotal role in advancing common rail injector technology, offering solutions that empower diesel engines with enhanced fuel efficiency, reduced emissions, and unparalleled reliability.

TEST EQUIPMENT FOR HPI INJECTORS AND TP ACTUATORS.CUMMINS/SCANIA

EQUIPMENT FOR HPI INJECTORS

With our team together with the cam-box you can perform the following tests

• Nozzle leak test
• Element pressure test.
• Return valve test.
• Injection advance and delay test.
• Delivery Flow.

Principal functions:

• Internal set of flow and advance control valves.
• Easy-to-use software, with semi-automatic tests.
• Test report.

EQUIPMENT FOR TP ACTUATORS

Equipment designed to perform tests and calibration of injection flow and time actuators.

• Static leak test.
• Dynamic Leak Test
• Flow test in 3 different conditions.
• Electrical race test.
• Isolation Test.

Principal functions:

• Dynamic flow measurement with high precision probes.
• Automatic feed pressure adjustment
• Easy-to-use software, with automatic tests.
• Database.
• Test Reports.
