Dead man type descent
Manoeuvrability

Specifications:
- fast lifting dual pump system
- foam protection on handle
- foot pedal with rubber pad
- anti-overload system
- swiveling rubber saddle
- nylon wheels
- min. H.: 95mm
- max. H.: 515mm
- dimensions: L.772xW. 367xH.1225mm
- weight: 39.5kg

The table facilitates the management of the installation or removal of batteries on electric cars, as well as various components.
It can support loads of up to 1500kg.
Made in Europe.

A pneumatic control system allows effortless, fast and precise control of the height.
The safety is ensured by a system of pneumatically operated side racks.
The plate unfolds for a maximum surface of 1400-1600mmx800mm, and is tapped M10x1.5 to receive various accessories allowing the removal of organs.
With the help of 2 screws driven by a 17mm hexagon, it is possible to act on the flatness of the table +/- 5%, and laterally +/- 3,5cm, for a great precision of positioning.
The telescopic frame of the table from 1650mm to 1850mm allows the reception of very large batteries.
Two lateral reservations under the frame of 170mm wide spaced of 750mm, allow the transport of the table with a forklift.

High load 1500Kg
High precision of settings

Specifications:
- h. min.: 550mm
- h. max.: 1800mm
- rise time (depending on the load) : 70-110 sec
- lowering time (depending on the load): +- 30 sec
- platform length: 1400-1600mm
- platform width: 800mm
- overall length of telescopic frame: 1650mm to 1850mm
- equipped with two wheels made of aluminium and polyurethane : 2 fixed and 2 swivel with brake
- max hydraulic pressure : 190bar
- pneumatic supply : 6-8bar
- weight : 400kg

Universal digital pressure gauge, allows the measurement of all types of pressure, wether it is PNEUMATIC or HYDRAULIC.

This version is intended for the following controls:
- gasoline engine compression
- diesel engine compression by the injector, optional or fake spark plugs available
- oil pressure, to be connected to the standard connection (not supplied) see option if necessary
- low fuel pressure
- pressure adblue PSA, others...
- depression
- particle filter
- cooling circuit
- turbo
An optional 2000 bar high pressure test kit and an accessory for motor leak test are also available.

Clear and precise reading of live values

The instrument is equipped with a sound and visual safety device to identify the sensor according to the measurement, the calibration is simple and integrated into the instrument.
Registration for expertise.

Contents:
- 1 TFT color display tester 7" with resistive touch screen
- battery: lithium polymer 3.7V / 2000mA
- USB smart battery charging with LED indicator
- PC connection via USB port
- ABS case with rubber bumpers
- all screws are mounted on brass inserts
- 1/4 thread brass insert at the back to fix the bracket
- 1 sensor 0/300 bar (2m)
- 1 sensor -1/+3 bar (2,90m)
- 1 universal diesel compression adapter
- 1 universal fuel compression adapter
- 12 quick connectors, original manufacturer, extremely flexible
All components are available at retail

This mobile device allows to drain, check the tightness, clean, create a vacuum to purge the cooling circuit and fill it, thanks to its venturi system coupled to a pressure gauge.
Ensures an ecological intervention since almost all the used coolant in the cooling system is recovered; allowing the user to disassemble any engine component without the need for coolant flow.

Fast intervention
No pollution of the ground

Specifications:
- 2 independent 15-liter tanks for storing polluted and new liquid
- 2 manometers for tank control
- connection to the expansion tank via a conical adapter
- 3 dip tubes of different lengths
- 4 swivel wheels
- dimension: L.430xl.610xH.1350mm
- weight: 43kg

Functions:
- used liquid extraction
- depression
- new liquid filling
- emptying used liquid tank
- emptying new liquid tank

Options:
- AC1021: Cooling system filling/draining hose adapters
- AC1022: Gravity cooling system drain adapter
