Dead man type descent
Manoeuvrability

Specifications:
- fast lifting dual pump system
- foam protection on handle
- foot pedal with rubber pad
- anti-overload system
- swiveling rubber saddle
- nylon wheels
- min. H.: 95mm
- max. H.: 515mm
- dimensions: L.772xW. 367xH.1225mm
- weight: 39.5kg

The table facilitates the management of the installation or removal of batteries on electric cars, as well as various components.
It can support loads of up to 1500kg.
Made in Europe.

A pneumatic control system allows effortless, fast and precise control of the height.
The safety is ensured by a system of pneumatically operated side racks.
The plate unfolds for a maximum surface of 1400-1600mmx800mm, and is tapped M10x1.5 to receive various accessories allowing the removal of organs.
With the help of 2 screws driven by a 17mm hexagon, it is possible to act on the flatness of the table +/- 5%, and laterally +/- 3,5cm, for a great precision of positioning.
The telescopic frame of the table from 1650mm to 1850mm allows the reception of very large batteries.
Two lateral reservations under the frame of 170mm wide spaced of 750mm, allow the transport of the table with a forklift.

High load 1500Kg
High precision of settings

Specifications:
- h. min.: 550mm
- h. max.: 1800mm
- rise time (depending on the load) : 70-110 sec
- lowering time (depending on the load): +- 30 sec
- platform length: 1400-1600mm
- platform width: 800mm
- overall length of telescopic frame: 1650mm to 1850mm
- equipped with two wheels made of aluminium and polyurethane : 2 fixed and 2 swivel with brake
- max hydraulic pressure : 190bar
- pneumatic supply : 6-8bar
- weight : 400kg

This tool after vacuuming allows an autonomous emptying indoors as well as outdoors in the workshop.

The scale on the used oil bowl allows you to control the quantity of oil withdrawn.
Ideal for vehicles that do not have a level control sensor.

Specifications:
- transparent pre-chamber with level indicator
- 1.5m suction hose with valve and quick connect for probes
- gravity draining
- vacuum draining
- air inlet pressure: 6 to 8bar
- Ø tray: 520mm
- pre-chamber capacity: 9l
- air pressure for oil discharge: 0.5bar
- oil level indicator
- weight: 32,3kg
- h. min.: 1350mm
- h. max.: 1795mm

This mobile device allows to drain, check the tightness, clean, create a vacuum to purge the cooling circuit and fill it, thanks to its venturi system coupled to a pressure gauge.
Ensures an ecological intervention since almost all the used coolant in the cooling system is recovered; allowing the user to disassemble any engine component without the need for coolant flow.

Fast intervention
No pollution of the ground

Specifications:
- 2 independent 15-liter tanks for storing polluted and new liquid
- 2 manometers for tank control
- connection to the expansion tank via a conical adapter
- 3 dip tubes of different lengths
- 4 swivel wheels
- dimension: L.430xl.610xH.1350mm
- weight: 43kg

Functions:
- used liquid extraction
- depression
- new liquid filling
- emptying used liquid tank
- emptying new liquid tank

Options:
- AC1021: Cooling system filling/draining hose adapters
- AC1022: Gravity cooling system drain adapter
