BENTON FLX Series photovoltaic panel features double-sided ETFE material which is corrosion-resistant. these high efficiency photovoltac panels absorb more sunlight and are very durable.

Designed for extreme applications such as yachets and RVs. Robust design with 4mm thickness. Easy installationand available in 60,100,120,150,180,220 and 270 watts

Deep Cycle Lithium Battery

• Ultra-Slim LiFePO4 , 12V|100Ah
• Ultra Slim Steel Case with In-Built Mounting Points, just 75mm high
• Integrated High Current 175A Battery Management System (BMS)
• Made of brand new Grade A cells
• Delivers up to 200A
• Fitted with two 120A and one 175A quick connect Anderson adaptors
• BMS Protections : Low voltage ,high voltae,over temp ,over current,short-circuit protection

Parameters

• Rated Capacity 100Ah
• Rated Energy 1280Wh
• Nominal Voltage 12.8V
• Max Charging Voltage 14.6V
• Discharge Cut-off Voltage 10V
• Max Continuous Discharge Current 175A
• Max Pulse Discharge (10 seconds) 300A
• Maximum Charging Current 100A
• Recommended Charge Current: 20-50A
• Operating Temperature (Charging) 0°C to +50°C
• Operating Temperature (Discharging) -20°C to 60°C
• Life Cycles > 3000 cycles @ 80% DoD
• Self Discharge: <3 % per month
• Terminals 1x 175A Quick Connect + 2x 120A Quick Connect
  Included Wiring 2x 150mm length 120A to 50A Quick Connect Adapters
  1x 175A Quick Connect plug + crimp terminals
• CE RoHs FCC, UN38.3 Approvals

• Input voltage: DC 12/ 24/ 48V;
• Output voltage: AC 220/ 230V;
• Efficiency (Max.): 90-93%
• 20A terminal block ; 1x European socket; USB QC3.0
• Type C 18W
• Product size: 320x211x72cm

Our BENTON In-Vehicle DX Series DC - DC Battery Chargers are engineered to charge your batteries to 100%, irrespective of their sizes. These chargers provide great benefit in saving money by maximizing battery life by using 7-step unique charging algorithm, increase run time of appliances eliminate voltage drop caused by long cables

Features of our chargers

• Automatic Input Selection
• Dual Charging Mode
• Ignition Connextion
• Multi Chemistry Charging
• Solar MPPT Regulator
• Wide Operating Range
• Temperature Compensation
• Super Quiet Operation
• Optional Accessory (Terminal Block)
• Compatable Battery Monitor
• Parallel Connection Units

Models Available

• 15A
• 25A
• 40A

BENTON Battery Chargers are multi-step fully automatic switch mode battery chargers and mantainers, designed for charging a variety of lead -acid rechargeable batteries, widley used in motorbikes , cars and several other vehicles.

Our chargers are able to charge various batteries types such as WET/Flooded,GEL , AGM and Lithium Ion batteries

Our chargers are able to charge batteries in cold condition and can diagnose rescued drain batteries

Our Battery Chargers are available with below amperage

• BX-4M (1A)
• BX-1M/1D (3.8A)
• BX-2M/2D (7.5A)
• BX-5M (25A)
• BX-6M (4 x 4A)
• BX-7M (15A)

Our Chargers complies and approved by relevant EU norms
