BENTON Battery Chargers are multi-step fully automatic switch mode battery chargers and mantainers, designed for charging a variety of lead -acid rechargeable batteries, widley used in motorbikes , cars and several other vehicles.

Our chargers are able to charge various batteries types such as WET/Flooded,GEL , AGM and Lithium Ion batteries

Our chargers are able to charge batteries in cold condition and can diagnose rescued drain batteries

Our Battery Chargers are available with below amperage

• BX-4M (1A)
• BX-1M/1D (3.8A)
• BX-2M/2D (7.5A)
• BX-5M (25A)
• BX-6M (4 x 4A)
• BX-7M (15A)

Our Chargers complies and approved by relevant EU norms

Deep Cycle Lithium Battery

• Ultra-Slim LiFePO4 , 12V|100Ah
• Ultra Slim Steel Case with In-Built Mounting Points, just 75mm high
• Integrated High Current 175A Battery Management System (BMS)
• Made of brand new Grade A cells
• Delivers up to 200A
• Fitted with two 120A and one 175A quick connect Anderson adaptors
• BMS Protections : Low voltage ,high voltae,over temp ,over current,short-circuit protection

Parameters

• Rated Capacity 100Ah
• Rated Energy 1280Wh
• Nominal Voltage 12.8V
• Max Charging Voltage 14.6V
• Discharge Cut-off Voltage 10V
• Max Continuous Discharge Current 175A
• Max Pulse Discharge (10 seconds) 300A
• Maximum Charging Current 100A
• Recommended Charge Current: 20-50A
• Operating Temperature (Charging) 0°C to +50°C
• Operating Temperature (Discharging) -20°C to 60°C
• Life Cycles > 3000 cycles @ 80% DoD
• Self Discharge: <3 % per month
• Terminals 1x 175A Quick Connect + 2x 120A Quick Connect
  Included Wiring 2x 150mm length 120A to 50A Quick Connect Adapters
  1x 175A Quick Connect plug + crimp terminals
• CE RoHs FCC, UN38.3 Approvals

• Input voltage: DC 12/ 24/ 48V;
• Output voltage: AC 220/ 230V;
• Efficiency (Max.): 90-93%
• 20A terminal block ; 1x European socket; USB QC3.0
• Type C 18W
• Product size: 320x211x72cm

Our BENTON In-Vehicle DX Series DC - DC Battery Chargers are engineered to charge your batteries to 100%, irrespective of their sizes. These chargers provide great benefit in saving money by maximizing battery life by using 7-step unique charging algorithm, increase run time of appliances eliminate voltage drop caused by long cables

Features of our chargers

• Automatic Input Selection
• Dual Charging Mode
• Ignition Connextion
• Multi Chemistry Charging
• Solar MPPT Regulator
• Wide Operating Range
• Temperature Compensation
• Super Quiet Operation
• Optional Accessory (Terminal Block)
• Compatable Battery Monitor
• Parallel Connection Units

Models Available

• 15A
• 25A
• 40A
