Feature:

* New Lever design without pins at both sides:

provide smooth touch for palm without pain

* Double injection ergonomic handle:

one hand operated for tiny space & two hands operated for wide area

confortable grip to reduce fatigue

* Bigger Vacuum tube:

provide further vacuum performance

model: WS-120 series

Pad Dia:

5" / 6"

Orbital Dia:

2.5/ 5 / 9.5 mm

Vacuum Mode:

Non-Vac./ Self-Vac./ Central Vac.

Free Speed: (no load)

12,500 RPM

Free Speed: (w/5kg load)

11,500 RPM

HP:

0.3 hp

Air Pressure:

90 psi

Noise:

90.5 dB(A)

Air Cons.:

15.9 cfm
(450 L/min)

Air Inlet:

1/4"

Min Hose Size:

3/8"

1/4" Hex. Super Duty Air Impact Screwdriver

Features:

• Patent pented 2 steps throttle trigger for precise control .
• Ergonomic designed for long time work without weary.
• Two hammer mechanism, vibration is small, suitable for Phillips screw works.
• Handle exhaust, 360° free rotating.

WS-303Std. Bolt CapacityM6~M8Impact MechanismTwo HammerTorque @ 0.5 sec50 NmTorque @ 2 sec57 NmFree Speed8,500 rpmAir Consumption @Load5.6 cfm (160 L/min)Length172 mmWeight1.05 kgAir Pressure90 psi (6.2 bar)Air Inlet1/4"Min. Hose Size1/4" (6.35 mm)Package 10 pcs / 12 kg / 13 kg / 0.93'

WS-662 Throttle TypeLeverMax. Grinding Wheel4" (100 mm)Free Speed11,800 rpmSpindle Thread SizeM10 x 1.5 (Female)Overall Length210 mmWeight1.47 kgAngle Head Height68 mmAir Inlet3/8"Min. Hose Size3/8" (9.5 mm)Max. Air Consumption9.2 cfm (280 L/min)Air Pressure90 psi (6.2 bar)Noise95.1 dB(A)Packing15pcs / 26kg / 27kg / 1.4'

˙This high quality simple tool can quickly and effectively grinds valves in seconds.

˙It comes with 16mm, 20mm, 30mm, 35mm and 45mm sucker heads to fit most valves.

Model

Valve Capacity

Blows Per Min

Avg. Air Cons.

Length

Weight

Air Pressure

Air Inlet

Min. Hose Size

in (mm)

BPM

cfm (l/min)

mm

kg

psi (kg/cm2)

in

in (mm)

WS-601K

45mm

800

1.77(50)

289.1

0.65

90 (6.2)

1/4"

1/4"(6.35)

5SET/CTN/11.5kgs/12.5kgs/2.6CUFT
