Intella-Sense III Combustible gas Leak Detector
At the heart of this 55975 leak detector is a new low power metal oxide gas sensor with superior performance properties such as lower current consumption and sensor longevity. The new sensor is characterized by high sensitivity and fast response upon detecting the presence of extremely small levels of chlorofluorocarbon gases. For this reason, this sensor was selected and integrated into the 55975 Combustible Gas Leak Detector. In addition, a powerful microprocessor was integrated into the design that automatically selects the best operating condition for the sensor to ensure optimum performance throughout its life. 55975 Intella Sense III Combustible Gas Leak Detector in a blow molded case with 2 “C” batteries, leak test vial and replacement filters DETECTS: Acetone, Acetylene, Ammonia, Benzene, Butane, Butanol, Chlorine, Ethane, Ethanol, Gasoline, Hexane, Hydrogen, Hydrogen Sulfide, Isobutane, Methane (natural gas), Methanol, Methyl Acetate, Methyl Chloride, Methyl Ether, Naptha, N-Butane, Pentane, Propane, Propanol, Sulfer Dioxide and Trichloroethane 55975 COMBUSTIBLE GAS LEAK DETECTOR III
SPECIFICATIONS • Sensing Element: Heated Tin Oxide • Sensor Life: 2000 hours • Refrigerants: Detects combustible gases (see below) • Response Time: less than 1 second • Battery: 2 “C” Alkaline 6000 mAh batteries • Operating Temperature Range: 0˚F to 120˚F • Ultimate Sensitivity: 50 – 1000 ppm • Probe: • Intelligent tip, with environment sensing element to eliminate the potential of false alarms. • Flexible 15.5 inch probe length for difficult to reach locations. • Display: Six vertical LED’s enabled selectively (red, yellow or green) to display the following information to the user such as: • The relative signal level of the detected leak • The selected sensitivity range (low/medium or high) of the unit • Diagnostic information : low battery, interference/wait, contaminated atmosphere readiness of the unit or fault conditions of the unit • Keypad Controls: • ON/OFF button (push-on/push-off) • Volume/Mute button (high, low or mute) • Sensitivity button for High, Medium and Low sensitivity level selection • Peak button when multiple leaks are suspected (push enable/disable)
