• For simple and safe leakage pressure testing of current air conditioning systems with the refrigerants R744 (CO2), R1234yf and R134a.
• Leak detection on A/C systems with contrast media is no longer permitted!
• KLDS 05 is introducing forming gas (N2 95 %/H2 5 %) into the A/C system, using a high performance pressure regulator. A pressure drop and thus a leak can be determined very quickly and easyly.
• The fall in pressure can be read off easily and precisely.
• The practical trolley offers enough storage space for all six test hoses, each 3.0 m long, accessories, removed parts and tools and space for safe transport of 2 gas bottles á 10 L.
• The structure of the trolley ensures a safe stand and very good maneuverability thanks to two large and high quality wheels.
• 2 safety valves (20 and 100 bar), prevents damage to the A/C system and ensure maximum user protection.
• Valve for controlled release of the test pressure.
• Knurled nut for quick and easy assembly and dismantling the pressure reducer.
• Secure HP and LP couplings for R744 (CO2), R1234yf, R134a air conditioners.
• High-quality components "Made in Germany" guarantee a safe and long-lasting use, even in harsh workshop environments.
• W 000 588 19 21 00 - Recommended by Mercedes Benz

• For simple and safe leakage pressure testing and leak localization* on current air conditioning / refrigeration systems with the refrigerants R1234yf and R134a. The testing of air conditioning systems with contrast medium is no longer permitted!
• High-precision pressure testing on the high pressure and low pressure side.
• With integrated test report printer for creating a test report.
• Documentation security through real-time clock (time and date cannot be changed)
• Leak test without contrast medium
• Leakage pressure test with nitrogen
• Leak localization* with forming gas
• * An additional electronic leak detector (ELS 04) is required to locate leaks
• Digital display, easy to read and accurate
• Measurement accuracy 0.5%
• Display 0.01 bar
• Mobile use thanks to the integrated battery
• Recorded pressure test of min. 10 minutes to max. 24 hours*

• For fast, professional and precise leak testing of various components
• E.g. for leak testing on high-voltage battery housings of hybrid and electric vehicles
• Leak test in a vacuum (-200 mbar) and / or pressure range (+200 mbar) can be carried out
• Special HV connection * for introducing vacuum or pressure into the battery housing (* HV = High Voltage)
• Detection of low pressure drop
• High-performance quality product made in Germany
• all individual parts available as spare parts

Technical specifications:

• Measuring range: -200 mbar ... + 200 mbar
• Accuracy: 0.5% FS
• Resolution: 0.1 mbar (0.0001 bar)
• Pressure drop method

• The new compression pressure measurement for the modern and innovative workshop.
• With the KP_BT 01_LR from Autotestgeräte Leitenberger, compression pressure values ​​are recorded and transmitted to a terminal device, e.g. a smartphone or tablet.
• The measurement data can be analyzed quickly and easily in a specially developed "LR Smart Tools" app and documented for customers.
• The app is free for all users and can be downloaded for Android and IOS in the corresponding stores.
• Suitable for use on single and multi-cylinder engines.
• Compression pressure measurement with high quality Leitenberger Bluetooth sensor.
• Measurement and immediate visualization and evaluation ("live data" transmission).
• Data transfer to end devices (e.g. smartphones, tablets, etc.) via Bluetooth technology.
• Forwarding of the measurement results via PDF, email, airprint, etc.
• Graphic evaluation and storage of the measured values ​​in a PDF document.
• "1-man test" possible, i.e. Operate the starter and read the compression pressure readings at the same time.
• Range for data transmission approx. 15 m.
• No consumables (such as print chart cards, paper rolls, etc.) thanks to the completely digital process.
• The operation of this device is only intended within the EU. This device is NOT approved for use outside the EU.

Technical specifications

• Measuring range: 0… 60 bar
• Accuracy: class 0.5
• Bluetooth version: BLE 5.1
• Communication: Bluetooth, low energy
• Integrated display: no, only via Bluetooth to an end device
• Compression pressure adapter: not included in delivery
• Weight: 0.8kg
• Dimensions: L x W x H 25 x 6 x 20.5 cm
• App for iOS from version 13.0
• App for Android from version 8.0

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG. Inc. and are used by Autotestgeräte Leitenberger GmbH under license.

• For simple and safe leakage pressure testing of current air conditioning systems with the refrigerants R744 (CO2), R1234yf and R134a.
• Leak detection on A/C systems with contrast media is no longer permitted!
• KLDS 05 is introducing forming gas (N2 95 %/H2 5 %) into the A/C system, using a high performance pressure regulator. A pressure drop and thus a leak can be determined very quickly and easyly.
• The fall in pressure can be read off easily and precisely.
• The practical trolley offers enough storage space for all six test hoses, each 3.0 m long, accessories, removed parts and tools and space for safe transport of 2 gas bottles á 10 L.
• The structure of the trolley ensures a safe stand and very good maneuverability thanks to two large and high quality wheels.
• 2 safety valves (20 and 100 bar), prevents damage to the A/C system and ensure maximum user protection.
• Valve for controlled release of the test pressure.
• Knurled nut for quick and easy assembly and dismantling the pressure reducer.
• Secure HP and LP couplings for R744 (CO2), R1234yf, R134a air conditioners.
• High-quality components "Made in Germany" guarantee a safe and long-lasting use, even in harsh workshop environments.
• W 000 588 19 21 00 - Recommended by Mercedes Benz

• For simple and safe leakage pressure testing and leak localization* on current air conditioning / refrigeration systems with the refrigerants R1234yf and R134a. The testing of air conditioning systems with contrast medium is no longer permitted!
• High-precision pressure testing on the high pressure and low pressure side.
• With integrated test report printer for creating a test report.
• Documentation security through real-time clock (time and date cannot be changed)
• Leak test without contrast medium
• Leakage pressure test with nitrogen
• Leak localization* with forming gas
• * An additional electronic leak detector (ELS 04) is required to locate leaks
• Digital display, easy to read and accurate
• Measurement accuracy 0.5%
• Display 0.01 bar
• Mobile use thanks to the integrated battery
• Recorded pressure test of min. 10 minutes to max. 24 hours*

• For fast, professional and precise leak testing of various components
• E.g. for leak testing on high-voltage battery housings of hybrid and electric vehicles
• Leak test in a vacuum (-200 mbar) and / or pressure range (+200 mbar) can be carried out
• Special HV connection * for introducing vacuum or pressure into the battery housing (* HV = High Voltage)
• Detection of low pressure drop
• High-performance quality product made in Germany
• all individual parts available as spare parts

Technical specifications:

• Measuring range: -200 mbar ... + 200 mbar
• Accuracy: 0.5% FS
• Resolution: 0.1 mbar (0.0001 bar)
• Pressure drop method
