Wheel balancer

All Twin Busch wheel balancers comply with the latest standards and test guidelines and are designed for professional wheel balancing. Furthermore, all wheel balancers are designed for high load capacity and long life. High-precision measuring electronics always ensure fast and accurate work.

TWF-100

The TWF-100 is a perfect basic model (hand-operated) and is also perfect for very limited space. It has a handbrake for locking the shaft when wheel mounting, balancing and braking. The balancing accuracy is, as with all our wheel balancers, 1g. Furthermore, like all our wheel balancers, the TWF-100 has a static and dynamic balancing program for car and motorcycle wheels.

TWF-150

The TWF-150 is our basic model and is perfectly suited for small and normal volume. The balancing accuracy is, as with all our wheel balancers, 1g. Furthermore, like all our wheel balancers, the TWF-150 has a static and dynamic balancing program for car and motorbike wheels. In addition, the TWF-150 and the TWF-00 have a manual measuring program, which ensures high balancing accuracy. In addition, the TWF-150 has the same software as the TWF-00.

TWF-00 | TWF-23 | TWF-95 | TWF-96 | TWF-96-G

Our TWF-00, like our TWF-23, TWF-95 and TWF-96, has a larger housing than our TWF-150. The TWF-00 has an extremely long drive shaft of 255 mm, which is advantageous for wide tyres. The shaft diameter of the TWF-00, TWF-23, TWF-95 and TWF-96 is 40 mm, while the shaft diameter of the TWF-150 is 36 mm. In addition, the main bearings of the TWF-00, TWF-23, TWF-95 and TWF-96 have a larger diameter. The TWF-23, TWF-95 and TWF-96 have an automatic programme recognition and semi-automatic value reading, which allows fast working at high throughput. Furthermore, the TWF-23, TWF-95 and TWF-96 have a foot brake to fix the shaft during wheel clamping or unbalance correction. The TWF-95 and TWF-96 have very extensive equipment with 2 electric feeler arms for rim distance, rim width and rim diameter. In addition, an LED light illuminates the rim for better visibility. In addition, the TWF-95 and TWF-96 have a laser position system for precise application of adhesive weights at 6 o'clock and 12 o'clock position (also possible at 12 o'clock position without laser). The large TFT monitor ensures good readability and visibility of the values. The TWF-96 also has pneumatic wheel tensioning. With the TWF-96-G model, we also offer an anthracite grey version.

TWF-50T

The TWF-50T is our wheel balancing machine for truck and light truck wheels, in addition, the balancing of car wheels is also possible. This has a wheel lift, a parking brake pedal and a high maximum wheel weight of 165 kg.

TWX-300

The TWX-300 wheel lifter / pneumatic lift for effortless clamping of heavy wheels is the optimal addition for a professional and ergonomic workplace at your tyre balancing machine. (Compressed air required).

TW115

Computer-controlled axle alignment with comfortable and user-friendly software. (data-base for vehicles included). Menu navigation in english and german. Clear display of measurement results. Wireless data transfer.

TW316

The TW316 is a 3D wheel aligner with a high-speed moving camera system with 4 cameras. With this system we offer the possibility for workshops to measure and adjust cars accurately and efficiently. Electric lifting device for camera carrier with Follow-Me function. Step-by-step operation of the software with graphic indicator for further procedure. The 3D measuring system enables fast/exact recording of the vehicle's ACTUAL values. The measurement and adjustment can be done at any desired height of the lift. The TW316 system determines and calculates the following axle parameters on the vehicle: front axle single toe and total toe incl. toe-in curve, camber, caster, spread, included angles. Rear axle single toe and total toe, camber. Furthermore wheelbase, wheel offset, track width, axle offset. For more than 20,000 vehicle types. It is possible to enter your own data into the database.

TWSWE-A

Our TWSWE-A complies with the latest guidelines for checking the adjustment of headlights. It is equipped with a fine adjustments wheel, which allows easy adjustment of main and fog headlights. In addition, the device is equipped with a digital luxmeter, and a cross visor.

TWSWE-A-PRO

It is equipped with a handwheel with markings, this enables easy setting and adjustment of headlights and fog lights. It is equipped with a handwheel with markings, this enables easy setting and adjustment of main and fog lights. In addition, the device is equipped with a digital luxmeter, laser sight and incl. type approval by the TÜV (with type approval number TP). Maximum vehicle headlight height: 1.20 m

TWSWE-B

Our TWSWE-B complies with the latest guidelines for checking and setting headlights. It is equipped with a 4 meter rail system as well as Laservisier, Laserpointer and Digital-Luxmeter. In addition, the device is equipped with a rotatable guide rod with foot pedal and has a design approval by the TÜV.

TWSWE-D

Our TWSWE-D corresponds to the newest guidelines for the testing and adjusting of automotive head lamps. The SLS Self-Leveling-System is able to compensant an uneven floor vertically and horizonzaly up to the legal max within 1-2 seconds. The unit consists of a CMOS-camara, 10 inch tablet as well as a laser visor, laser pointer and a digital luxmeter. The unit also includes a turnable guide rod with a foot pedal and an article inspection from the TüV (Inspection Number TP). Optional is an ASA interface.

TWK-270L

Compressor 270 L. Fully equipped with a one-way valve, adjustable pressure switch with ON / OFF switch, and motor start load protection. Safety valve, pressure gauge, ball valve and condense water drain plug, including air tank certificate.

TWK-270S

Compressor 270 L. Fully equipped with a one-way valve, adjustable pressure switch with ON / OFF switch, and motor start load protection. Safety valve, pressure gauge, ball valve and condense water drain plug, including air tank certificate.

TWK-500L

Compressor 500 L. Fully equipped with a one-way valve, adjustable pressure switch with ON / OFF switch, and motor start load protection. Safety valve, pressure gauge, ball valve and condense water drain plug, including air tank certificate.

TWK-500SL

Screw compressor 500 L. Fully equipped with a one-way valve, adjustable pressure switch with ON / OFF switch, and motor start load protection. Safety valve, pressure gauge, ball valve and condense water drain plug, including air tank certi­ cate. Control unit (with power saving star circuit function, electronic monitoring of pressure and temperature, automatic notification of service intervals, possible remote control of the compressor, protection and auto emergency shut down.

TWK-200L

Horizontal Compressor 200L. Equipped with back pressure valve, pressure reducer, adjustable On/Off pressure switch with start up safety valve, Pressure gauge and condense water release tap.
