2835 DV12V/DC24V 120LED/m LED Strip
Electrical Data
- Number Led/M: 120LEDs/M
- Power W/m±10%: 12W
- Width for finished product: 8mm/10mm
- CRI:>80/90
- Max length(10% voltage drop): 5M
- Cut Size: 25mm/50mm
Standards / Normative Requirements
- Eye security: ICE 62471 ICE60778
- Protection class: EN 60529
- Safety Requirements Protection grade:: EN62031 EN60598-1
- ROHS: Yes
- Resch: Yes
Product Features
LED: Use ultra-high brightness led, light decay small, long service life, energy saving and environmental protection.
PCB: Using the FPC DC a soft substrate, Can be arbitrary bending will not break, easy to shape, Can be cut according to the PCB cutting line.
Operating voltage: DC12V/24V Low voltage power supply, more Security and stability.
Installation mode: Sticker on the back of 3M glue using fixed card clamps, convenient installation.
Operating Temperature: -40º+65ºC
Storage Temperature: : -40º+85ºC
