Electrical Data

• Number Led/M: 120LEDs/M
• Power W/m±10%: 12W
• Width for finished product: 8mm/10mm
• CRI:>80/90
• Max length(10% voltage drop): 5M
• Cut Size: 25mm/50mm

 Standards / Normative Requirements

• Eye security: ICE 62471 ICE60778
• Protection class: EN 60529
• Safety Requirements Protection grade:: EN62031 EN60598-1
• ROHS: Yes
• Resch: Yes


Product Features

LED: Use ultra-high brightness led, light decay small, long service life, energy saving and environmental protection.

PCB: Using the FPC DC a soft substrate, Can be arbitrary bending will not break, easy to shape, Can be cut according to the PCB cutting line.

Operating voltage: DC12V/24V Low voltage power supply, more Security and stability.

Installation mode: Sticker on the back of 3M glue using fixed card clamps, convenient installation.

Operating Temperature: -40º+65ºC
Storage Temperature: : -40º+85ºC
