Low Profile Double Scissor Lift
- Witheasy installations and does not needing to recessed
its a good alternative to other lifts.
- Only 135 mm drive-on height.
- 2 way drive-through.
- With its small size it doesn’t cover too much space.
- Small and space-saving energy unit.
- İt can be stopped in any height and maximum safety with
double cylinders system.
- No compressed air required.
- Powerfull lifting capacity even at the lowest height.
- Syncronized plate movement via hydraulic equalization.
- High stability.
- CE certifcate.
- It can be recessed (Optional).

Lifting Capacity 4000 kg
Minimum Height 135 mm
Distance Between Platform 860 mm
Platform Width 610 mm
Platform Length 1550-2100 mm

Electro-Hydaulic Scissor Lift
- Pneumaticmechanical locking system.
- Hydraulic emergency valve.
- Lowering speed regulators.
- Electro hydraulic synchronisation prevents any balance problems and
makes smooth rising and lowering.
- Can be used for mechanical reparing.
- Reparing will be safer due to robustness and board platorms of lift.
- With low profile reduced the ramp length and saves space.
- Can be recessed (Optional).
- Lamps can be integrated on platorms (Optional).
- The lift can be produce flat platform, Wheel alignment or
- Wheel free request of customer.
- It can be produces as recessed to request f customer.
- Scissor type or telescopic jack beams. (Optional)

Electro-Mechanic Mobile Column Lifts
- Possibility to use as 4, 6 and 8 according to vehicle tire number.
- Instant monitoring of the height of each column via the main control panel.
- Electronic synchronization between columns via PLC control system.
- Emergency stop button in each column.
- Safety system with autoblocking (trapezoidal screw).
- High safety with safety nut in case of main nut wear.
- Detecting any errors on LCD screen via switches and sensors impedded on
the column
- Adjustable forks for different tire diameters. (Optional)
- Thanks to the Transpalet switch, the column can not be used while loaded
on the pallet truck.
- Part recognition switch under carrier.
- Load take-up switch located on carrier noses. (Optional)
- The fork located on the lift can be produced according to the customer’s
request.

Lifting Capacity : 3000 kg - 5500 kg - 7500 kg (Per Column)

Electro Hydraulic Two Post Lift
- Hydraulic unit without base frame between columns, controlled via
electrohydraulic, column design
- Synchronization with steel rope
- Maximum safety via pressure relief valve and check valve.
- Spring loaded safety clutch allowing parking carrier at each 100mm
- Manuel Locking System
- Hydraulic cylinders having long life-span
- Tapered arm locking gears
- Low height lifting pads
- Same lowering time regardless of load by the means of pressure
compensated valves fitted into each cylinders
- Audible warning signal when lift approaches ground level CE stop
(Foot protection system)
- High stability carriage and column design with effective sliding guides
- Powder paint coating for excellent corrosion protection
- Magnetic Locking System (Optional)
- Joggled extensions. (Optional)
- Power set 1 x 220 V
- Compressed air outlet (Optional)
