Operation

1. Connect to the power source:

• Connect the red connector to the positive terminal.
• Connect the black connector to the negative terminal.

2. Turn the power on:

• The operation is normal when the power indicator is green.
• If the power indicator turns yellow, there is a malfunction.
• The machine is equipped with a protective device to prevent damage from improper operation.

3. Use only 1-2 ml of baby oil.

4. Press the start button to begin heating. The indicator will turn yellow during heating. After 90 seconds, there will be sufficient smoke for testing. To stop heating, press the start button again. The heating will start automatically after 5 minutes. Add baby oil as needed.

Notice:

• Use only commercially certified baby oil.
• For DC-12V only.
• The power will automatically turn off in 5 minutes.
• If the indicator light flashes yellow, it indicates that the fuse has burnt out.
