Using simple design style，easy to match in the bedroom. Shell material uses the top class fireproof PC，built-in micro energy collection module, no wiring, no battery and no any power supply. Our products with very high cost performance. Each wireless kinetic switch has a unique identity code that does not generate erroneous control. The emission energy is only one percent of bluetooth with no harmful radiation.

Work Category: Key Switch
Power Mode: Self Powered(No Battery)
Work Frequency: 433MHZ
Operation Life: >200K
Number of Keys: 1 Key
Shell Material: Fireproof PC
Transmission: 20M(indoor), 80M(outdoor)
Dimensions: L86mm * W86mm * H22.5mm
Work Temperature: -20°C〜55°C
Waterproof: IP65
Receiver Load: 10A on Maximum.
The receiver can also work with APP by WiFi.

Pendant LED Linear Light Aluminum Profile
Size W55mm * H70mm
LED Driver built inside the profile
Easy Steel Rope Hanging Installation
With Staight, L, T, X shape Connectors
Aluminum Profile 6063-T5 good heat dispersion
Frost or Opal PC Cover Diffuser.

With modern design, it is suitable for furniture / room lighting Etc.

Substantial aluminum mass provide good heat sink for high power leds.

> Match Flexible LED Strips: 3 or 4 lines of LED Strip. > Material: Anodized Aluminum Extrusion. > With I shape connector. > Cover: Frosted PC Cover. > Length: 2 meter. > Mounting: Pendant. > With LED Driver inside.

New Flip Chip On Board Flexible LED Strip, 576 chips per meter,  8mm width, Constant Voltage 24V, 2 Ounces Double Layer FPCB, CRI 80. Every section 27.8mm can be cut.
1. Ideal for LED lighting application to avoid multi-shadows .
2. Higher heat conductivity for better thermal management.
3. Provide variable and innovative array LED layout designs and combinations

4. 50000 hours life span..

• Ideal for LED lighting application to avoid multi-shadows. • Higher heat conductivity for better thermal management. • Provide variable and innovative array LED layout designs and combinations. • Available in 24V DC maximum. • Very bright & low power consumption. • Operating temperature: -20~50°C. • Long life span LED lights, more than 50,000 hours.

Touch Dimmer Switch for LED Aluminum Profile TD002-TM

This Touch Switch can be installed in the led aluminum profile. Simply touch the PC Cover above the spring of the touch switch can turn the led strip light on or off, or hold for dimming.
No soldering needed with quick connector for wires and led strip.

• Touch switch ON/OFF with dimming function.
• Input Voltage: 12V-24VDC.
• Output Voltage: 12V-24VDC.
• Input Current: 3A.
• Input Wire: 26~20AWG.
• Connecting LED Strip Thickness: 0.4~0.6mm.
• Connecting LED Strip Width: 8~10mm.
• Height of spring: 20mm.
• Load around 36W for 12V, or 72W for 24V.
• Dimension: 52.5*11mm.

The Super LED Light Bar is easy to be put onto the metal shelf in the supermarket. Substantial aluminum mass provides good heat sink for high power LEDs. This model is good for shelf lighting on metal rack in supermarket or malls. The model equipped with strong magnet plate on the back of the aluminum profile.

• 24VDC
• 14.4W per meter
• 1200lumens per meter
• 0, 30, 45, 60 degree mounting bracket is available
• Customized length can be ordered.
