Anhui Bosintech Intelligent Technology Co., Ltd.

PISTON PIN

Beschreibung

Grindtech Piston Pins are made from high quality Alloy Steel (16MnCr5,17Cr3, SCM415, SAE8620 etc) and are of fine microstructure. The Manufacturing is performed on the state of the art machinery to achieve perfect dimensions (Roundness  within 2 microns, Concentricity Max 0.3mm, Surface Finish 0.1Ra Max.) and quality. All the Pins are hardened and tempered and are maintained between 58HRC to 64HRC hardness  and case depth of 0.5mm to 1mm. These Pins are mainly made for Pistons made by Grindtech, but for past many years , other Piston manufacturers also rely on Grindtech Pins Only.

Range : Dia 25mm to 250mm

Materials: Aluminium Alloy LM-13, Graded Cast Iron

Coatings: Anodising, Graphite Coating, Tin Coating, Phosphating

Types : Flat Dome Type, Reverse Dome Type, Hollow Dome Type, Alfin (with Ni-Resist ring) Type, Strut Type, Oil Cooler type etc.

Quality Commitments: Accuracy is maintained in all fronts weight, Dimentions, Raw materials. All the Piston s are heat treated to provide best efficiency and non expansion at elevated temperatures. All the Piston produced are subjected to various inspection tests such as weight, Dimensional check (Diameter, Height,Cam, Ovality,Pin Bore, Stroke/Compression Ratio,Cavity Volume etc,),Hardness Porosity.

Adresse

Anhui Bosintech Intelligent Technology Co., Ltd.
Anhui Anqing
Wangjiang Development Area No. 7 Wenhui Road,
246000
China

Telefon+86 556 727 9222

Fax+86 556 725 0000
