MAIN FEATURES

Microprocessor controlled

5-inch color touch screen

Wi-Fi connection for software and database updates

Easy to use control panel

Electronic scale

High-efficiency refrigerant recovery that meets ARI standards

Automatic follow-up of programmed operations

Vehicle database

Can be configured to work with R134a or R1234yf after discharging all the refrigerant from the storage tank

High sensitivity vacuum sensor

Automatic leak detection (visible and audible)

Automatic tank full warning & shut off

High sensitivity pressure sensor

High sensitivity temperature sensor

Automatic air purge

Filter-drier to remove the acid, moisture, and particles from the refrigerant

Custom design oil separation unit for the reuse of the recovered oil

Used oil drain

New oil injection

High-speed refrigerant charging

High-pressure protection system

Maintenance reminders for filter-drier, vacuum pump oil, and compressor oil

Refrigerant management system to track charged, recovered, and added refrigerant

TECHNICAL SPECIFICATIONS

Compressor: 3/8 hp 12 cc hermetic

Vacuum Pump: 6 m³/h (100lt/min)

Low Pressure Gauge: 15 Bar

High Pressure Gauge: 30 Bar

Display: 5 inch color touch screen

Electronic Scale Resolution: +/- 5 gr

Refrigerant Tank Capacity: 15 kg

Filter Capacity: 150 kg

Refrigerant: R1234yf - R134a

Hose: 300 cm

Temperature Range: 8-49 °C

Max. Recovery Rate: 450 gr/min

Size: 55 cm X 53 cm X 111 cm

Weight: 76 kg

Power Supply: 220V ± 10% / 50 Hz

Optional Features

Printer

Storage Tank Capacity: 25 kg

Storage Tank Capacity: 35 kg
