• Suitable to verify and adjust any kind of headlamp (Measures both in % or cmt10 m the slope of the high, low and fog light beams), including headlights with XENON and LED lamps.
• For light and heavy vehicles.
• Besides  complying  with  EC regulations, they  are also approved by the TÜV (Nr.TPN100151836).
• PC Computer connection trough USB, Bluetooth and WiFi.
• Allows connection to any commercial USB, Bluetooth or WiFi printer.
• Laser alignment visor + central laser pointer to easily positioning of the unit in front of the vehicle.
• Rotating mast allows turning of the body of the headlight tester over the axis of the bar.
• Height adjustment system with counterweight inside the mast that allows up-down movement with less than 0.5 daN.
• Power: Li-lon batteries up to 12h work capacity) with input for an external battery charger 230Vac.
• Comfortable use due to the positioning of the wheels. Robust anti-tip base.
• Supplied with assembly, operation and calibration manuals and EC Declaration of Conformity.
• 10 inches touch screen with Windows 10 tablet included.
• High quality 1.3 Megapixel CMOS camera.
• All the software is designed to be very easy to use (with guided menus)
• Resolution of measures: 0,1 %

• Suitable to verify and adjust any kind of headlamp (Measures both in % or cmt10 m the slope of the high, low and fog light beams), including headlights with XENON and LED lamps.
• For light and heavy vehicles.
• Besides  complying  with  EC regulations, they  are also approved by the TÜV (Nr.TPN100111737).
• PC Computer connection trough USB, Bluetooth and WiFi.
• Allows connection to any commercial USB, Bluetooth or WiFi printer.
• Laser alignment visor + central laser pointer to easily positioning of the unit in front of the vehicle.
• Rotating mast allows a 360° turning of the body of the headlight tester over the axis of the bar.
• Height adjustment system with locking system.
• Power: Li-lon batteries up to 12h work capacity) with input for an external battery charger 230Vac.
• Comfortable use due to the positioning of the wheels. Robust anti-tip base.
• Supplied with assembly, operation and calibration manuals and EC Declaration of Conformity.
• 10 inches touch screen with Windows 10 tablet included.
• High quality 1.3 Megapixel CMOS camera.
• All the software is designed to be very easy to use (with guided menus)
• Resolution of measures: 0,1 %

The electronic surge protectors from LUJAN have been developed to protect the car’s electronic equipment against the electric surges, like the ones generated during welding on the car’s body, the battery’s charge or the starting aid with an external battery .

THE ELECTRONIC SURGE PROTECTORS MUST BE CONNECTED BEFORE PERFORMING ANY OF THE FOLLOWING OPERATIONS OVER
THE VEHICLE:
Welding on the vehicle’s body
Battery’s charge
Starting aid with an external battery

• Suitable to verify and adjust any kind of headlamp (high,low and fog lights),including headlights with XENON and LED lamps.
• Appropriate for use both in garages and Test Lanes. For light and heavy vehicles.
• Besides complying with  EC regulations, they are also approved by the Hannover TuV, for usage in TuV workshops in Germany (certificate  nr. TPN100083443).
• Internat regulable measuring screen with scale for both right and left hand drive vehicles.
• Laser alignment  visor +  centrat Laser pointer  to easily positioning of the unit in front of the vehicle.
• Height adjustment system with locking system.
• Digital Luxmeter. (powered by a 9V battery  type 6F22)
• Comfortable  use due  to  the  positioning  of  the wheels.
• Robust anti-tip base.
• Supplied with assembly, operation and calibration manuals and EC Declaration of Conformity.
• All models are able to adapt the Rotating Mast Kit ref.54121KG (See Accesories catalogue)

• Suitable to verify and adjust any kind of headlamp (high, low and fog lights), including headlights with XENON and LED lamps.
• Appropriate for use both in garages and Test Lanes. For light and heavy vehicles.
• Internal aiming screen with scale for both right and left hand drive vehicles.
• Steel wire alignment visor with calibration system.
• Height adjustment system with locking system.
• Digital luxmeter. (powered by a 9V battery type 6F22)
• Comfortable use due to the positioning of the wheels.
• Robust anti-tip base.
• Supplied with assembly, operation and calibration manuals and EC Declaration of Conformity.
