The SCC calibration system replaces the calibration with adhesive tape, wooden slats and folding rule of side cams on commercial vehicles.

• Special centred wheel alignment clamps, which can be quickly attached to the drive axle to check the required parallelism to the geometrical driving axle.
• Fast setup of the measuring crosshead and positioning of the targets within 5 minutes.
• Use of a red cross beam laser for better visibility on different workshop floors.
• Height-adjustable measuring crosshead for use on workshop pits.
• Practical traversing target in white for use on surfaces with different colours.
• The laser distance meter ensures exact positioning of different traversing targets relative to the defined distances.
• Calibration is executed through the vehicle diagnostic software.
• Battery powered laser measuring heads for extremely flexible use in the workshop.

The starter kit consists of a QuickPlate and the DuoExpert. Both products are the base for precise wheel-alignment.

The variable flange plate adapter QuickPlate is indispensable for perfect mounting of the vehicle wheelat the wheel balancing machine. The QuickPlate simulates the correct clamping pressure, as the wheel nuts on the car. This ensures an optimum balancing result.The rotating eccentric unit makes it easy to determine the bolt circle. Once you have determined the pitch circle, the Pro Lock System fixes the setting for the whole set of tyres.

DuoExpert is the tolerance-free hub centering system for steel and alloy wheels. It is used instead of the conventional centering sleeves and cones. DuoExpert’s full effect is experienced when it is completely emerged in the centering flange under pressure. The rim is centered in its middle and lies completely in the flange. This simulates the exact fit on the wheel hub of the vehicle. With a possible clamping range of 54 mm to 94 mm, approx. 95 % of all passenger cars are covered.

The AXIS series for axle alignment on commercial vehicles was extended by the SAD systems.
Using the SAD500, a check and adjustment of the driver assistance systems on commercial vehicles can be carried out.

• The SAD500 has been developed in order to be able to carry out a check and for the adjustment of an Adaptive Cruise Control sensor (ACC sensor) on commercial vehicles.
• It is an additional module that, in combination with the AXIS500, is used to measure the ACC sensor and for aligning the calibration panel for multifunction cameras of Advanced Driver Assistance Systems (ADAS).
• Quick an reliable checks and adjustment of the ACC sensor on different types of vehicles (with the respective accessories required) in the „drive position“.

The smart mobile camera system for wheel alignment of commercial vehicles

The AXIS4000 axle alignment system is an innovative cutting-edge product of years of experience with mobile wheel alignment. It enables modern, highly precise and fast gauging. The global high demands in vehicle measurements – in connection with flexible and precise measurement technology – have given HAWEKA the tip to further develop this measurement method. With the AXIS4000, an axle measurement system was created that corresponds to the required handling and measurement precision standards of truck wheel alignment systems.

• Fast measurement of the single and total toe, centering of the steering gear, camber, castor, kingpin inclination, toe-out-on-turns, max. steering angle, tilt and the axle offset
• Wireless transmission of the measurement values to the log
• Computer based wheel alignment – scale alignment via software
• Quick installation on the steel rims thanks to different magnetic holders
• Also ideal for aluminum rims thanks to ProClamp, the quick-action clamping device (gripper-arm holder system)
• Measurement done in normal driving condition of the vehicle – no lifting is required
• Fast recording of the required nominal value using the 360° rotatable camera measurement heads
• Direct display of the setup on the monitor
• Protocol with measurement and setup values “before/after”

AXIS500 is a laser wheel alignment system for measuring commercial vehicles including inclinometer with automatic angle recognition. Using the mobile wheel alignment system AXIS500, all types of vehicle can be quickly and reliably measured.

• Measure in drive position; no raising necessary
• All vehicles are reliably measured using a measuring system
• Recording the measurement values by an inclinometer
• Simple installation onto the rims using magnets
• Quick-clamping device for all aluminium rims
• Measuring head with battery/laser technology can be rotated through 360°
• Quick measurement of the complete and individual track, camber, track differential angle, caster, inclination of the axles, axle offset and centre positioning of the steering gear
• At each measurement, the vehicle frame is included
• Recording of the measurement value within 15 min., incl. setting-up time
• Only one person is required for the complete wheel alignment
• The good price-performance ratio ensures quick amortisation
• Mobile, solid box for the device is included in the scope of delivery
