The Merlin EM Series are a range of test stands designed for the calibration of traditional in-line and rotary fuel injection pumps of various sizes from all the main manufacturers.

Available with 20 or 30 bhp drives with 8 or 12 cylinder options.

The EM range can now cater for most manufacturers Common Rail Pumps and Injectors as well as integrating with the Hartridge HK1400 Expert EUI and EUP test solution.

The EM Series benefits from a highly precise electronic metering system that utilises 8 to 12 individual flowmeters depending on the model.

This is displayed on a 24” LCD monitor.

Full training on all the applications can be given at Merlin Diesel HQ and we have a dedicated technical support team which is contactable via video link.

APPLICATIONS:

• ‘A’ type Inline BOSCH, SIMMS and MINIMEC.
• Mechanical/Rotary BOSCH, DELPHI, STANADYNE, DENSO and ZEXEL.
• Hartridge HK1400 All Makes EUI/EUP Cambox.
• Submersible pumps (appropriate Cambox required).
• Common Rail Pumps and Injectors from BOSCH, DELPHI, CONTINENTAL VDO and DENSO.

Our range of fuel pumps, covering:

• Bosch CR
• Bosch CR
• Bosch EDC Inline
• Bosch/Zexel EDC Rotary
• Bosch EUP
• Bosch/Zexel Inline
• Bosch VP30/VP44
• CAT C Series
• Delphi CR
• Delphi DP Series
• Delphi Epic
• Delphi EUP
• Delphi Inline
• Delphi Rotary
• Denso HP Series
• Denso Inline
• Denso Rotary
• Denso V Series
• Fuel Lift Pumps
• Single Cylinders
• Stanadyne D Series
• Stanadyne Mechanical
• VDO CR
• Yanmar Mechanical
• Zexel Covec
• Zexel VRZ

Our injector range, covering:

• Bosch CR
• Mechanical - Bosch, Delphi, Denso, Stanadyne, Yanmar
• Bosch PD
• Bosch Piezo
• Bosch Sensored
• CAT C7/C9
• CAT C Series (EUI)
• CAT Navistar (HEUI)
• CAT 3500 (EUI)
• Delphi CR
• Delphi EUI
• Delphi Smart
• Denso CR
• GDI Petrol - Delphi, Bosch, VDO
• Perkins CR
• VDO CR
• Yanmar Mechanical

Introducing the MDS 7000, Multi Functional Test Stand For All Applications

Complete test solution covering: Common Rail Fuel Pumps, Common Rail Injectors, CAT/Perkins Fuel Pumps, HEUI fuel pumps & Injectors, HEUI & EUP, HPI, Q60 & X15

Easy To Use, Accurate, Flexible, Submerged CAT pump, Easy access for maintenance, Large work area with sliding door, S1000 Coding software included, Testplans Included, Digital 24" monitor

40L Tank Capacity, 220 x 780 x 1780mm, 20hp variant, 30-4000 rpm, 1 x 0-800cc gear flowmeter, 3 x 0-1500 cc gear flowmeters, temperature control, 220-240v/3 phase/60hz, 380-440v/3 phase/50hz, 160 ltr/hr water supply, air cooling in development

For further info, email: testequipment@merlindiesel.com
