Flatbed laminating machines in various designs with respective periphery acc. to customers´requirements

MEYER Flatbed-Laminator-Systems
are double belt presses with integrated contact heating and cooling. The materials that are laminated are heated very gentle. Due to the long heating zone the materials are laminated perfectly with high bonding strength. Right after the heating the materials can be pressed together or calibrated to a set thickness with the pressure rollers. To stabilize this compound the materials a cooled down before they exit the double belt press. With the flat gap between the belts and the precise height adjustment even rigid plates with a thickness of up to 150mm can be laminated.

Process parameters

• Heating time = production speed
• Temperature in heating zone
• Pressure of pressure rollers
• Gap of pressure rollers (level adjustment)
• Height adjustment = gap between belts
• Temperature in cooling zone



Adhesive
Normally thermoplastic adhesives are used when using a Meyer flatbed laminating machine. These adhesives are environmentally friendly, easy to handle and there are special adhesive types for nearly all applications. Also the requirements for recycling, sort purity, fogging, environment and health care are easily achieved with thermoplastic adhesives.
Depending on the application and the requirements also other adhesive systems, like reactive adhesives can be easily combined with Meyer flatbed laminators.

Machine for following apllications:

foil coatings

powder coating

pressure sensitive coating

2- and multilayer laminates

calibrating

thermo-bonding

surface-smoothing

Fusing machines in various designes for textile and clothing industry

Meyer is one of the leading manufacturers for fusing machines used in the garment industry. In the sector of continuous fusing machines, Meyer offers the suitable machine for every application at different widths. Stacker and loading belts make this large selection complete. Numerous options enable an optimal adaptation to customers‘ requirements.

molding lines for automotive industry

Depending on the application we design machines with different dimensions and press forces, as well as manual simple systems or full automatic molding lines.

Molding lines for

• carpets
• trunk covers
• door panels
• headliner
• parcel shelves

Fusing machine especially designed and optimized for laminating leather

3 temperature zones

pressure rollers with precise gap setting

cooling system inside loading belt

innovative SIEMENS control

for application of powdery material

for thermoplastic adhesive powder or other powdery material

precise and uniform application

flexible and maintenance-friendly

respirable dust extraction system
